Operator's manual
GB
+ INSTRUCTIONS FOR PRODUCT DELIVERY . . . Page 3
"Translation of the original Operating Manual"
NOVACAT A10 ED/RC
(Type 3850 : + . . 00001)
• Disc mower
Nr.
99 3850.GB.80R.0
