Section 5: Software

Set Conversion Point

COMMAND
TYPE
DESCRIPTION
SYNTAX
RETURNS
EXAMPLE
NOTE

Convert Conversion Point

COMMAND
TYPE
DESCRIPTION
SYNTAX
RETURNS
EXAMPLE
NOTE
INSERT
Set
Inserts one EU pressure to ADC pressure counts entry into the points conversion table, per chan-
nel and temperature range. These points are created during a full temperature calibration, and
should not be modified manually. These terms are used to create a polynomial fit coefficient using
the CONVERT command and are not used for EU conversions.
INSERT <raw temp> <channel> <pressure> <adc counts>
Where:
<raw temp> is the raw A/D counts that represent the temperature of the module
<channel> is the channel number from 1 to 16
<pressure> is the pressure in PSI (real value)
<adc counts> is the A/D counts at the specified pressure, as a signed integer from −8,388,608
to 8,388,607
Prompt when ready to accept a new command.
// Insert a master point for channel 1 at 30°C (raw counts read 1234422). The applied pressure is
11.9998 psi, the measured counts are 2416376
INSERT 1234422 1 11.9998 2416376
>
This command can modify or change the coefficient table which may result in inaccurate or unus-
able data. This command should not be used in the field.
CONVERT
Function
Retrieves the current INSERT settings and uses these points to create the least-squares conversion
values (K) along with the error correction values (A, B, C, D).
CONVERT CAL [<num temps>]
Where <num temps> is the number of temperatures in the insert list.
Prompt when ready to accept a new command.
// after inserts have been loaded into RAM, convert these points into the EU conversion terms
CONVERT CAL
>
This command can modify or change the coefficient table which may result in inaccurate or
unusable data. This command should not be used in the field unless instructed by a Scanivalve
representative.
