Set Programmable Gain

COMMAND
TYPE
DESCRIPTION
SYNTAX
RETURNS
DEFAULT
EXAMPLE
NOTES

List Points Table

COMMAND
TYPE
DESCRIPTION
SYNTAX
RETURNS
EXAMPLE
NOTES
PGA
Set
Set the current programmable gain settings. These settings are set by Scanivalve at the factory
and should not be modified manually.
PGA [<channel>] <gain>
Where:
<channel> = is optional, and is used to select the channel number from 1 to 16
<gain> = the gain multiplier
If only one argument is provided, the DSA assumes this to be the gain setting for all channels.
Prompt when ready to accept a new command.
Varies
// set PGA to 1 for channel 4
PGA 4 1
>
This command can modify or change sensor behavior which may result in inaccurate or unusable
data. This command should not be used in the field.
LIST INSERT
Get
Retrieves the current points coefficient stored in the RAM of the DSA.
LIST INSERT [<start temp> <end temp> [<channel>]]
Where optional arguments:
<start temp> is the lowest temp plane to be returned from 0 to 72
<end temp> is the highest temp plane to be returned from 0 to 72
<channel> is channel number from 1 to 16
INSERT <raw temp> <channel> <press> <adc counts>
::: ::: ::: :::
INSERT <raw temp> <channel> <press> <adc counts>
Where:
<raw temp> is the raw temp counts
<channel> is the channel number
<press> is the pressure in PSI
<adc counts> is the A/D counts at the specified pressure
Followed by a prompt when ready to accept a new command.
// Retrieves the full coefficient table
LIST INSERT
INSERT 100234 1 -5.958100 -215944
::: ::: ::: :::
INSERT 502345 16 5.958100 301360
>
While optional, <start temp> and <end temp> must be used together.
