Section 5: Software

Precision Time Protocol Variables (LIST PTP)

The precision time protocol settings control the PTP 1588 settings of the DSA5000. The PTP configuration is accessed by the
command LIST PTP.

LIST Precision Time Protocol Settings (LIST PTP)

DESCRIPTION
SYNTAX
RETURNS
EXAMPLE

PTP Enable (PTPEN)

COMMAND
TYPE
DESCRIPTION
SYNTAX
RETURNS
EXAMPLE
EXAMPLE
DEFAULT

PTP Statistical Output (STAT)

COMMAND
TYPE
DESCRIPTION
SYNTAX
Returns all of the PTP settings
LIST PTP
All of the PTP setting followed by the prompt.
LIST PTP
PTPEN 1
STAT 0
SST 0:0:0.000000
SSD 1971/1/1
UTCO -7:00:00
MAXOFM 0
>
PTPEN
Set/Get
Enables the precision time protocol engine in the DSA5000, or retrieves the current setting. When
enabled, the DSA will listen for PTP information on the network and communicate with any found
PTP Grandmasters.
PTPEN <status>
Where <status> is:
0 = PTP engine disabled
1 = PTP engine enabled
PTPEN <status>
- and/or -
Prompt when ready to accept a new command.
// enable the DSA to listen for PTP information on the network
PTPEN 1
>
// Retrieve the PTP engine status
PTPEN
PTPEN 0
>
0
STAT
Set/Get
Sets the destination of PTP statistical output, or retrieves the current setting.
STAT <level code>
Where <level code> is:
0 = off
1 = serial
