List Programmable Gain Settings - Scanivalve DSA5000 Series Operation And Service Manual

Section 5: Software
SYNTAX
RETURNS
EXAMPLE
NOTES

List Programmable Gain Settings

COMMAND
TYPE
DESCRIPTION
SYNTAX
RETURNS
DEFAULT
EXAMPLE
NOTES
TEMP <channel> <temp index> <temperature> <adc count>
Where:
<channel> is the channel number from 1 to 16
<temp index> is the temperature plane point from 0 to 14
<temperature> is the temperature in °C
<adc counts> is the A/D counts at the specified pressure, as a signed integer from −8,388,608
to 8,388,607
Prompt when ready to accept a new command.
TEMP 1 6 48.000000 4418741
>
This command can modify or change the coefficient table which may result in inaccurate or unus-
able data. This command should not be used in the field.
LIST PGA
Get
Retrieves the current programmable gain settings for all channels.
LIST PGA
PGA <channel> <gain>
:: :: :: ::
PGA <channel> <gain>
Where:
<channel> is the channel number from 1 to 16
<gain> is the gain multiplier
Followed by a prompt when ready to accept a new command.
Varies
LIST PGA
PGA 1 1
PGA 2 1
PGA 3 1
PGA 4 1
PGA 5 1
PGA 6 1
PGA 7 1
PGA 8 1
PGA 9 1
PGA 10 1
PGA 11 1
PGA 12 1
PGA 13 1
PGA 14 1
PGA 15 1
PGA 16 1
>
The temp conversions used in RAM may be different than the temp conversions stored on flash.
Use the TYPE command plus the file name to find the temp conversions stored in flash.
