Frames Per Scan (Fps); Ascii Formatting (Format) - Scanivalve DSA5000 Series Operation And Service Manual

DSA5000
EXAMPLE
EXAMPLE
NOTES

Frames Per Scan (FPS)

COMMAND
TYPE
DESCRIPTION
SYNTAX
RETURNS
DEFAULT
EXAMPLE
EXAMPLE

ASCII Formatting (FORMAT)

COMMAND
TYPE
DESCRIPTION
SYNTAX
// To configure the DSA output of data to 100Hz
RATE 100
>
// To retrieve the current setting
RATE
RATE 150
>
Scan rate may be limited based on output format.
FPS
Get/Set
Sets the number of frames to output during a scan, or retrieves the current setting. Once this
number of frames is met, the DSA will stop scanning and return to READY mode.
A Frame contains a sampled pressure value per channel output (8 or 16 channels total) plus time
stamp, frame number, temperatures, and other additional information defined by the data output
configured in the DSA.
The FPS variable can be used to scan for a timed duration using the following equation:
FPS = RATE x TIME (in seconds)
FPS <number of frames>
Where <number of frames> is the number of frames per scan. Valid values are 0 to 4294967295.
If number of frames is set to 0, the DSA will scan indefinitely until the scan is manually stopped
using the STOP command.
FPS <number of frames>
- and/or -
Prompt when ready to accept a new command.
1
// To configure the DSA to output 100 frames of data per scan
FPS 100
>
// To retrieve the current setting
FPS
FPS 1200
>
FORMAT
Get/Set
Sets the scan data output format for Telnet (ASCII output only), or retrieves the current setting.
FORMAT <format code>
Where <format code>:
F = VT100 Terminal Emulator
A = Unformatted ASCII
C = Comma Separated Variable (CSV)
47
47
Section 5: Software
