Hioki 9699 Instruction Manual

9699
SMD TEST FIXTURE
Instruction Manual
Aug. 2018 Revised edition 3 Printed in Japan
9699A980-03 18-08H

Warranty

Warranty malfunctions occurring under conditions of nor-
mal use in conformity with the Instruction Manual and
Product Precautionary Markings will be repaired free of
charge. This warranty is valid for a period of three (3) years
from the date of purchase. Please contact the distributor
from which you purchased the product for further informa-
tion on warranty provisions.

Introduction

Thank you for purchasing the HIOKI 9699 SMD TEST FIX-
TURE. To obtain maximum performance from the product,
please read this manual first, and keep it handy for future
reference.

Overview

This HIOKI 9699 SMD TEST FIXTURE can be directly
connected to the measurement terminals (UNKNOWN) of
the HIOKI LCR HiTESTERs for testing a SMD compo-
nent.

Specifications

Measurement frequency
DC to 120 MHz
range
Maximum apply voltage ±40 VDC
Dimensions of sample to Width:1 mm to 4 mm (0.04" to 0.16")
be tested Height: 1.5 mm (0.06") or less
Residual resistance
Short-circuited 100 mΩ max. (at 100 Hz)
Floating capacitance 2 pF max. (at 1 MHz)
between terminals
Dimensions and Mass Approx.100.5W x 28.6H x 40D mm
(3.96"W x 1.13"H x 1.57"D)
(excluding protrusions),
Approx.125 g (4.4 oz.)
Operating temperature
and humidity range
Storage temperature and
humidity range
Operating environment
Accessories
Product warranty period 3 years
Please check a HIOKI catalog for instruments to which this
product can be connected.
EN

Inspection and Maintenance

Initial Inspection

When you receive the product, inspect it carefully to en-
sure that no damage occurred during shipping. If damage
is evident, or if it fails to operate according to the specifi-
cations, contact your dealer or HIOKI representative.

Preliminary Checks

• Before using the product the first time, verify that it oper-
ates normally to ensure that the no damage occurred
during storage or shipping. If you find any damage, con-
tact your dealer or Hioki representative.

Maintenance and Service

• To clean the product, wipe it gently with a soft cloth
moistened with water or mild detergent. Never use sol-
vents such as benzene, alcohol, acetone, ether,
ketones, thinners or gasoline, as they can deform and
discolor the case.
• If the product seems to be malfunctioning, contact your
dealer or Hioki representative. Pack the product care-
fully so that it will not be damaged during shipment, and
include a detailed written description of the problem.
Hioki cannot be responsible for damage that occurs dur-
ing shipment.

Safety

Follow these precautions to ensure safe operation and to
obtain the full benefits of the various functions.
Mishandling during use could result in injury or
death, as well as damage to the product. Be certain
that you understand the instructions and precau-
tions in the manual before use. We disclaim any
responsibility for accidents or injuries not resulting
directly from product defects.

Safety Symbol

In the manual, the
larly important information that the user should
read before using the product.
The following symbols in this manual indicate the relative
importance of cautions and warnings.
Indicates that incorrect operation presents a
significant hazard that could result in serious
injury or death to the user.
Indicates that incorrect operation presents a
possibility of injury to the user or damage to
the product.
Advisory items related to performance or cor-
rect operation of the product.
0 to 40°C (32 to 104°F), 80% RH or
less (with no condensation)
-10°C to 55°C (14 to 131°F), 80% RH
or less (with no condensation)
Indoors, altitude up to 2000 m
(6562-ft.)
Instruction Manual, short bar
symbol indicates particu-
