SPECIFICATIONS
Inputs:
Line:
10K ohm input impedance
80mV rms sensitivity for 1.22V output
Mic:
600 ohm input impedance unbalanced
0.85mV rms sensitivity for 1.22V output
57mV rms max input
Phono:
47Kohm input impedance
1.3mV rms sensitivity @ 1KHz for 1.22V output
Outputs:
Line:
9V rms max
Headphone: 0.5W into 47ohm
Distortion: less than 0.01%
Signal to Noise Ratio: (maximum output) JIS-A weighted
Line:
Better than 92dB
Mic:
Better than 82dB
Phono:
Better than 85dB
Frequency response:
Line:
20Hz-20KHz +/-0.5dB
Mic:
20Hz-15KHz +/-0.5dB
Phono:
+/-1dB except for controlled attenuation of -3dB
@ 20Hz to reduce rumble and feedback
Channel equalizer:
Bass:
+12/-32dB @40Hz
Middle:
+12/-32dB @1KHz
Treble:
+10/-28dB @15KHz
Channel Kill:
Bass:
Better than 80dB at 40Hz
Middle:
Better than 80dB at 1KHz
Treble:
Better than 80dB at 15KHz
Power consumption:
19.2 Watt typical
21.6 Watt with full headphone output
Dimensions:
220mm(W) by 370mm(D) by 90mm(H)
Weight:
4.8 kgs
PAGE 19
