CONTROLS

1. Microphone Controls

"Mic" (Microphone Trim)
This knob adjusts the volume of the main microphone. When turned all the way to the left, the volume is
at -8dB. When turned to the right, the volume is at 0dB. The Microphone Trim should be set at -8dB when
connecting and disconnecting a microphone from the Quarter-Inch "Microphone" Input on the front panel
of the mixer
"Treble" (Microphone High EQ)
This knob adjusts the high-tone input sound of the microphone (1kHz). The center position for this control
is flat (0dB.) Turning this knob to the right increases the high-tone input sound of the microphone (to
+10dB at 1kHz.) Turning this knob to the left decreases the high-tone input sound of the microphone (to
-30dB at 1kHz.)
"Bass" (Microphone Low EQ)
This knob adjusts the low-tone input sound of the microphone (70Hz). The center position for this control
is flat (0dB.) Turning this knob to the right increases the low-tone input sound of the microphone (to
+10dB at 70Hz.) Turning this knob to the left decreases the low-tone input sound of the microphone (to
-30dB at 70Hz.)
"Microphone" (Quarter Inch Microphone Input)
One microphone can be connected to this Quarter Inch output terminal. The Microphone Trim should
always be at its lowest setting while connecting and disconnecting a microphone to prevent damage to
the mixer and/or your audience.
"Process" (Microphone FX Processing)
See Section 8 "Effects Processing Controls."
"PFL" (Microphone Pre Fade Level Cueing)
See Section 4 "Cueing Controls."
PAGE 5 MICROPHONE CONTROLS
