The IP Endpoint Company
1.0 Out-of-Box and Prior to Final Installation
1.1. Verify that you have received all of the parts listed on the Installation Quick
Reference placemat.
1.2. The ceiling tile is an adapter for the SIP-enabled IP Speaker. Download the
current manual, otherwise known as an Operations Guide, which is available
in the Downloads tab at the following webpage:
https://www.cyberdata.net/products/011521
Note You can also navigate to the Downloads tab by going to
www.CyberData.net
the following figures:
1
PRODUCTS
A
VOIP PRODUCTS
B
INFORMACAST ENABLED
C
2.0 Select Power Source
PoE Switch
Set PoE power type to Class 0 = 15.4W
Spanning Tree Protocol (STP) must be disabled or Portfast enabled
Quick Start Guide
InformaCast Enabled 2 x 2 Ceiling Tile Drop-In Speaker
Quick Start Guide
and following the steps that are indicated by
Make sure port is not in trunk mode
Set port to full duplex/ 100mbps
2
InformaCast Enabled Paging
A
011521 InformaCast Enabled
2x2 Ceiling Tile Drop-In Speaker
B
3
Downloads
PoE Injector
CAT6 cable recommended—
for longer distances
Be sure you are using a non-PoE switch or
port
931745A
Advertisement
Table of Contents
Related Manuals for CyberData InformaCast 011521
Summary of Contents for CyberData InformaCast 011521
- Page 1 1.2. The ceiling tile is an adapter for the SIP-enabled IP Speaker. Download the current manual, otherwise known as an Operations Guide, which is available in the Downloads tab at the following webpage: https://www.cyberdata.net/products/011521 Note You can also navigate to the Downloads tab by going to www.CyberData.net...
- Page 2 3.0 Power Test 3.1. Plug the ethernet cable into the RJ45 port on the back of the speaker enclosure. Monitor the switch port (and PoE injector, if applicable) LED activity for power and network link status. See the following figure: Ethernet cable 3.2.
- Page 3 4.0 InformaCast Configuration File Retrieval 4.1. DHCP should be enabled. After the speaker initializes, it will send a broadcast to the DHCP server to ask for the location of its InformaCastSpeaker.cfg configuration file. 4.2. SLP or TFTP? • SLP should be enabled on InformaCast version 5.0.4 or higher. SLP is an InformaCast protocol introduced in InformaCast version 5.0.4.
- Page 4 6.0 Contacting CyberData VoIP Technical Support You are welcome to call CyberData VoIP Technical Support at 831-373-2601 x333. Business hours are 7:00 AM - 5:00 PM Pacific Time, Monday through Friday. We encourage you to access our Technical Support help desk at the following address: http://support.cyberdata.net/...
