3.0 Power Test

3.1. Plug the ethernet cable into the RJ45 port on the back of the speaker

enclosure. Monitor the switch port (and PoE injector, if applicable) LED

activity for power and network link status. See the following figure:

3.2. The IP addressing mode is set to DHCP on default. If there is no DHCP

server available on the network, it will try 12 times with a three second delay

between tries and eventually fall back to the programmed static IP address

(by default 10.10.10.10). This process will take approximately 80 seconds.

This concludes the power test. Go to

Configuration File

Quick Start Guide

Retrieval".

Ethernet cable

Section 4.0, "InformaCast

931745A
