- Page 1 PUE CY10 WEIGHING INDICATOR OPERATING MANUAL ITKU-133-01-02-23-EN...
- Page 2 FEBRUARY 2023...
- Page 3 SAFETY MEASURES AND PRECAUTIONS Before you start installing, using or maintaining the device, you are required to get familiar with this operating manual and follow its guidelines. Before use, please read this Operating Manual carefully and use the device as per its intended use. Secure the device against excessive temperature fluctuations, solar radiation and UV radiation, substances that cause chemical reactions.
-
Page 4: Table Of Contents
Table of contents 1. INTENDED USE ..............................5 2. GUARANTEE TERMS............................5 3. CLEANING ................................. 6 3.1. Cleaning ABS Elements ..........................6 3.2. Cleaning Stainless Steel Elements ......................6 3.3. Cleaning Powder-coated Elements ......................6 3.4. Cleaning Aluminum Elements ........................7 4. -
Page 5: Intended Use
C. RADWAG shall not be held responsible for defects or losses deriving from unauthorized or improper production or servicing. D. The guarantee does not cover the following: ... -
Page 6: Cleaning
3. CLEANING To clean the device safely, unplug it in the first place. Next disassemble the weighing pan and other moving elements of the scale. If you clean the weighing pan while it is installed, you can damage the scale. 3.1. -
Page 7: Cleaning Aluminum Elements
A soft microfiber cloth will be the best choice. To clean polished surfaces, make circular movements. After removing all dirt, polish the surface with a dry cloth to dry the surface and make it glow. 4. STRUCTURE 4.1. Dimensions Dimensions of the PUE CY10 indicator... -
Page 8: Description Of Connectors
4.2. Description of connectors Reboot or on/off button Left loudspeaker Right loudspeaker USB type-A port USB type-A port Microphone Kensington Lock Ethernet port. Power supply power Power supply port – USB type-C HDMI port Media box port RFID sensor Reflective sensors Camera Camera LED light Signal LED light... -
Page 9: Technical Parameters
4.3. Technical parameters Max. number of verification units 10000 1200Ω Max impedance of load cell 50Ω Min. impedance of load cell 3,25µV Max voltage per verification unit 0,4µV Min voltage per verification unit Connection of load cells 4 or 6 wires + Screen Load cell supply voltage Max. -
Page 10: Home Page
Plug the feeder cable into the mains socket and put the feeder cable plug into the port at the back of the weighing indicator housing. The operating system and RADWAG software loading procedure will initiate in a moment. While the program is being launched, a signal LED light and LED lights at the lower frontal part of the indicator will flash. -
Page 11: Navigation In The Menu
The weighing result and scale leveling box is displayed below. The field provides additional information related to ongoing actions. Information in this field can be freely programmed. Defining method can be found in ‘PUE CY10 indicator software manual’. The on-screen functional buttons are showed below: The scale operator can define on-screen functional buttons. -
Page 12: Scale Keyboard
Press button a couple of times to make the scale return to home screen. Press in the lower bar to return to home page immediately. 8. INSTALLER Based on the PUE CY10 weighing indicator, load-cell scales can be constructed. -
Page 13: Connection Of The 6-Wire Load Cell
8.1. Connection of the 6-wire Load Cell A 6-wire load cell can be connected to the motherboard as showed in the figure below: Connection of a 6-wire cell load Radwag A/C transducer board Signals from load cell NOTES See 8.3... -
Page 14: Connection Of The 4-Wire Load Cell
8.2. Connection of the 4-wire Load Cell A 4-wire load cell can be connected to the motherboard as showed in the figure below: Connection of the 4-wire load cell Radwag A/C transducer board Signals from load cell NOTES See 8.3... -
Page 15: Connection Of Load Cell Screen
8.3. Connection of Load Cell Screen Load cell with galvanically Load cell without galvanical connected screen of the connection of the screen signal wire. of the signal wire Compact structure of the scale (scale Point A with indicator on the mast, arm, etc.). Scale with a weighing indicator in the metal housing... -
Page 16: Technical Specification
Load cell power supply Connection of load cells 4 or 6 wires + Screen Multi-range nature 9.1.2. Colors of Signal Wires from Weighing Platform Terminal marking (soldering pads) RADWAG marking Color on RADWAG A/C transducer boards +INPUT brown -INPUT green AGND +OUTPUT yellow... -
Page 17: Factory Parameters
10. FACTORY PARAMETERS When you activate the factory settings mode in the scale, you can change both user parameters and all factory parameters. This means that you can define parameters of the entire scale. 10.1. Access to Factory Parameters Remove the label that secures access to the motherboard button. Label securing access to motherboard button ... -
Page 18: List Of Global Parameters
Factory parameters access button Use to enter main menu with two submenus displayed: <Global> and <Factory>. 10.2. List of Global Parameters Menu NAME RANGE DESCRIPTION level Function for quick defining of the scale Scale defining with automatic setting of key metrological parameters. - Page 19 Standard, PGC Selection of program type: Comparator, Standard – all weighing modes available; Mass control, Comparator – weighing and comparison Moisture only; Mass control – weighing and mass Program mode analyzer, control only (automatic feeder); Sample PGC - scale with PGC mode (Packed magnetism, Goods Control).
-
Page 20: List Of Factory Parameters
Platform 1 parameters. Metrology Metrological settings. Selection of scale type (depending on type – relevant settings are available – Type PUE CY10, CY10 e.g. filters). Mass divisions Transducer divisions displayed. 0.0000001 50 Reading unit: range 1 Reading unit: range 1. - Page 21 Factory adjustment Value of adjustment factor calculated factor upon factory adjustment. Adjustment unit g, kg, lb Adjustment unit. External adjustment Mass of external adjustment weight. weight Gravity correction coefficient (see 10.6 0.9 1.1 Gcor of the manual). Stability Parameters related to stable result. Fast, Reliable Value release* Measurement result stabilization speed.
-
Page 22: Factory Adjustment
Weighing program Weighing module program version. version Service parameters of platform 1 Defined filter with activation and service definition of filter dynamics. Menu with platform 2 parameters Platform 2 (analogical to platform 1). Menu with platform 3 parameters Platform 3 (analogical to platform 1). -
Page 23: Determination Of Factory Start Mass
External factory adjustment of the additional platform is analogical to the above-stated description. 10.4.2. Determination of Factory Start Mass Enter <Factory> menu and select platform number. Go to <Weighing Module / Adjustment> submenu and enter <Determination of start mass> function. The following message will be displayed: <Unload Weighing Pan>. -
Page 24: Linearity Deletion
It allows proper adjustment of the scale away from the further use spot. The gravitational correction must be entered on the basis of tables provided by „RADWAG Wagi Elektroniczne” or through calculation as per the following equation: Gcor ...
