ETS NORD NORDfire Manual

Fdmb fire damper
Hide thumbs Also See for NORDfire:
Table of Contents

Advertisement

Quick Links

Download this manual
NORDfire
FDMB Fire Damper
Square dampers from 160×160 mm to 0,5 m2 (max. dimensions 1000×500 mm)
CE certified acc. to EN 15650
Fire resistance up to EIS 120
External Casig leakage class C, Internal leakage class 2 acc. to EN 1751
Damper actuating mechanical, or electrical

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NORDfire and is the answer not in the manual?

Questions and answers

Related Manuals for ETS NORD NORDfire

Summary of Contents for ETS NORD NORDfire

  • Page 1 NORDfire FDMB Fire Damper Square dampers from 160×160 mm to 0,5 m2 (max. dimensions 1000×500 mm) CE certified acc. to EN 15650 Fire resistance up to EIS 120 External Casig leakage class C, Internal leakage class 2 acc. to EN 1751...

  • Page 2: Table Of Contents

    ® NORDfire | FDMB Contents Description Design Dimensions, weighs and effective area Placement and Assembly Statement of installations Installation frames Suspension systems Pressure loss Noise data Material, finishing Inspection, testing Transportation and storage Assembly Entry into service and revisions Spare parts...

  • Page 3: Description

    ® NORDfire | FDMB General information Description Fire dampers are shutters in ducts of air-conditioning devices that prevent spreading the fire and combustion products from one fire segment to the other one by means of closing the duct in the points of fire separating constructions.

  • Page 4: Design

    ® NORDfire | FDMB 1.2 Working conditions Right damper function is secured under the following conditions: a) Maximum air circulation speed: 12 m/s; maximum pressure difference: 1200 Pa b) The air circulation in the whole damper section must be secured as steady on whole surface Operation of the dampers does not depend on the direction of air circulation.
  • Page 5 ® NORDfire | FDMB G905-300E03W1 Fig. 5 Limit switch 1 (COM) - must kaabel black wire 2 (NC) - hall kaabel gray wire 4 (NO) - sinine kaabel blue wire This limit switch is possible to connect in following two...
  • Page 6 ® NORDfire | FDMB 2.2 Design with actuating mechanism Design .40, .50 The damper are equipped by Belimo actuators with spring return and thermoelectric activation device of BFL, BFN or BF depending on the damper size (furher mentioned as „actuators“). After being connected to power supply AC/DC 24V or 230V, the actuating mechanism displaces the damper blade into operation position ”OPEN”...
  • Page 7 ® NORDfire | FDMB Fig. 9 Actuating mechanism BELIMO BFL (BFN) 24-T(-ST) S1 S2 <5° <80° Tab. 1. Actuating mechanism BELIMO BFL 24-T(-ST), BFN 24-T(-ST), BFL 230-T a BFN 230-T Actuating mechanism BELIMO BFL, BFN 230-T BFL, BFN 24-T(-ST) AC 24 V 50/60 Hz...

  • Page 8: Dimensions, Weighs And Effective Area

    ® NORDfire | FDMB Tab. 2. Actuating mechanism BELIMO BF 24-TN(-ST), BF 230-TN Actuating mechanism BELIMO BF 24-TN(-ST) BF 230-TN AC 24 V 50/60 Hz Nominal voltage AC 230 V 50/60 Hz DC 24 V Power consumption - motoring - holding...
  • Page 9 ® NORDfire | FDMB Fig. 12 Design with actuating mechanism (40+X)/2 B-X* B+40 B+40 * X=14 (A<160 or B<160) 37,5 * X=23 (AxB≤500x400) * X=36 (AxB>500x400) Seletus: Position: 1 - Tuletõkkeklapp 1 – Damper casing 2 - Ajam 2 – Actuating mechanism 3 - Klapilaba 3 –...
  • Page 10 ® NORDfire | FDMB effect. effect. Weight Weight A x B area Actu. Mech. A x B area Actu. Mech. mech servo mech servo (mm) mech. contr. (mm) mech. contr. Sef. Sef. (kg) (kg) (kg) (kg) 150 x 280 0,0271...
  • Page 11 ® NORDfire | FDMB effect. effect. Weight Weight A x B area Actu. Mech. A x B area Actu. Mech. mech servo mech servo (mm) mech. contr. (mm) mech. contr. Sef. Sef. (kg) (kg) (kg) (kg) 225 x 710 14,8...
  • Page 12 ® NORDfire | FDMB effect. effect. Weight Weight A x B area Actu. Mech. A x B area Actu. Mech. mech servo mech servo (mm) mech. contr. (mm) mech. contr. Sef. Sef. (kg) (kg) (kg) (kg) 315 x 600 15,1...
  • Page 13 ® NORDfire | FDMB effect. effect. Weight Weight A x B area Actu. Mech. A x B area Actu. Mech. mech servo mech servo (mm) mech. contr. (mm) mech. contr. Sef. Sef. (kg) (kg) (kg) (kg) 500 x 600 18,9...
  • Page 14 ® NORDfire | FDMB effect. effect. Weight Weight A x B area Actu. Mech. A x B area Actu. Mech. mech servo mech servo (mm) mech. contr. (mm) mech. contr. Sef. Sef. (kg) (kg) (kg) (kg) 650 x 225 52,5...
  • Page 15 ® NORDfire | FDMB effect. effect. Weight Weight A x B area Actu. Mech. A x B area Actu. Mech. mech servo mech servo (mm) mech. contr. (mm) mech. contr. Sef. Sef. (kg) (kg) (kg) (kg) 1000x280 18,8 20,0 0,1830...

  • Page 16: Placement And Assembly

    ® NORDfire | FDMB Placement and Assembly Fire dampers are suitable for installation in arbitrary position in vertical and horizontal passages of fire separating constructions. Damper assembly procedures must be done so as all load transfer from the fire separating constructions to the damper body is absolutely excluded.
  • Page 17 ® NORDfire | FDMB The control mechanism has to be protected (covered) against damage and pollution during installation process. All fire dampers has to be closed during installation process. The damper body should not be deformed in the course of bricking in. Once the damper is built in, its blade should not grind on the damper body during opening or closing.

  • Page 18: Statement Of Installations

    ® NORDfire | FDMB Statement of installations Tab. 4. Installation method list Wall/Ceiling Fire separating constru. Installation Fire resist. Page Min. thickness [mm] EIS 120 Mortar or gypsum EIS 90 Stuffing box with fire protection mastic EIS 60 EIS 60...
  • Page 19 ® NORDfire | FDMB 5.1 Installation in solid wall construction Fig. 18 Solid wall construction - mortar or gypsum EIS 120** ** the requirement to EIS 120 must be specified in ** EIS 120 nõue tuleb eraldi ära märkida. ≥ 100** EIS 120** the order alone.
  • Page 20 ® NORDfire | FDMB Fig. 20 Solid wall construction - fire protection foam with stucco plaster Maximal damper dimensions 400x400 mm EIS 60 EIS 60 Maksimaalsed tuleklapi mõõdud 400 x 400 mm EIS 45 EIS 45 EIS 30 EIS 30 ≥...
  • Page 21 ® NORDfire | FDMB Fig. 21 Solid wall construction - battery - mortar or gypsum EIS 90 EIS 90 Klappide vahele jääva vahe (94 mm) võib täita ka The gap 94 mm between dampers can be f illed by mineral stone kivivillaga, mille tihedus on 140 kg/m³.
  • Page 22 ® NORDfire | FDMB Fig. 22 Solid wall construction - installation next to wall, ceiling - mortar or gypsum and mineral wool. EIS 90 EIS 90 ≤ 75 ≤ 75 ≤ 75 ≥ A+150 ≥ 100 (≥ 100)+20 LOEND: 1 - Tuletõkkeklapp 2 - Kips või mört...
  • Page 23 ® NORDfire | FDMB Fig. 23 Solid wall construction - stuffing box, fire protection mastic and cement lime plate EIS 90 ≥ 100 ≥ 50* ≤ 75* * Around the perimeter Ensure symmetry with rod location 25 (±5) ≤ 300 ≤...
  • Page 24 ® NORDfire | FDMB Fig. 24 Solid wall construction - Weichschott EIS 90 B+60 to 800 A+60 to 800 ≥ 100 Position: 1 – Fire damper 2 – Solid wall construction Used materials - example: 3 – Fire resistant board 4 –...
  • Page 25 ® NORDfire | FDMB 5.2 Installation outside solid wall construction Fig. 25 Outside solid wall construction - mineral wool - mortar or gypsum EIS 60 * Around the perimeter ≤ 75* Position: 1 – Fire damper 2 – Solid wall construction 3 –...
  • Page 26 ® NORDfire | FDMB Fig. 26 Outside solid wall construction - mineral wool - stuffing box and protection mastic EIS 60 * Around the perimeter ≥ 20* ≤ 75* Position: Used materials - example:** 1 – Fire damper Promapyr, Rockwool Steprock HD, Hilti CFS-CT 2 –...
  • Page 27 ® NORDfire | FDMB Fig. 27 Outside solid wall construction - mineral wool, stuffing box, fire protection mastic and cement lime plate EIS 90 EIS 120 ***** ≥ 50* ≤ 75* * Around the perimeter L=Min. 400 L=Min. 100 T=120...
  • Page 28 ® NORDfire | FDMB 5.3 Installation in gypsum wall construction i Fig. 28 Gypsum wall construction - mortar or gypsum ≥ 100** EIS 120 EIS 90 Installation opening has to be reinforced by steel Uprofile. Profile is fixed by screws ≥3,5 mm with corresponding...
  • Page 29 ® NORDfire | FDMB Fig. 30 Gypsum wall construction - fire protection foam with stucco plaster Maximum damper dimensions 400 x 400 mm EIS 60 EIS 45 Installation opening has to be EIS 30 reinforced by steel Uprofile. Profile is fixed by screws ≥3,5 mm with corresponding length.
  • Page 30 ® NORDfire | FDMB Fig. 31 Gypsum wall construction - battery - mortar or gypsum EIS 90 The gap 94 mm between dampers can be filled by ≥ 94 mineral stone wool min. density 140 kg/m³. Wool is fixed to damper body by fire protection mastic.
  • Page 31 ® NORDfire | FDMB Fig. 32 Gypsum wall construction - installation next to wall, ceiling - mortar or gypsum and mineral wool EIS 90 ≤ 75 ≤ 75 Installation opening has to be reinforced by steel Uprofile. Profile is fixed by screws ≤...
  • Page 32 ® NORDfire | FDMB Fig. 33 Gypsum wall construction - stuffing box, fire protection mastic and cement lime plate EIS 90 Installation opening has to be reinforced by steel Uprofile. ≥ 100 Profile is fixed by screws ≥3,5 mm with corresponding length.
  • Page 33 ® NORDfire | FDMB Fig. 34 Gypsum wall construction - Weichschott EIS 90 Installation opening has to be reinforced by steel U-profile profile. Profile is fixed by screws ≥3,5 mm with corresponding length. Distance between screws ≤200 mm. B+60 to 800 A+60 to 800 ≥...
  • Page 34 ® NORDfire | FDMB 5.4 Installation outside gypsum wall construction Fig. 35 Outside gypsum wall construction - mineral wool - mortar or gypsum EIS 60 Installation opening has to be reinforced by steel U-profile. Profile is fixed by screws ≥3,5 mm with corresponding length.
  • Page 35 ® NORDfire | FDMB Fig. 36 Outside solid wall construction - mineral wool - stuffing box and protection mastic EIS 60 Installation opening has to be reinforced by steel U-profile. Profile is fixed by screws ≥3,5 mm with corresponding length.
  • Page 36 ® NORDfire | FDMB Fig. 37 Outside solid wall construction - mineral wool, stuffing box, fire protection mastic and cement lime plate. Installation opening has to be reinforced by steel U-profile. Profile is fixed by screws ≥3,5 mm with corresponding length.
  • Page 37 ® NORDfire | FDMB 5.5 Installation in solid ceiling construction Fig. 38 Solid ceiling construction - mortar or gypsum EIS 120 EIS 90 ≤ 75** Position: 1 – Fire damper 2 – Solid ceiling construction * min 110 – Concrete/ min. 125 - Aerated concrete 3 –...
  • Page 38 ® NORDfire | FDMB Fig. 40 Solid ceiling construction - battery - mortar or gypsum EIS 90 The gap 94 mm between dampers can be filled by mineral stone wool min. density 140 kg/m³. Wool is fixed to damper body by fire protection mastic.
  • Page 39 ® NORDfire | FDMB Fig. 41 Solid ceiling construction - stuffing box, fire protection mastic and cement lime plate EIS 90 ≥ 50** ≤ 75** Ensure symmetry with rod location 25 (±5) ≤ 300 ≤ 300 Threaded rod M8, 2x nut, 2x washer (rod length for 100mm wall is approx 150mm) 25 (±5)
  • Page 40 ® NORDfire | FDMB Fig. 42 Solid ceiling construction - Weichschott EIS 90 B+60 to 800 A+60 to 800 Position: * min 110 – Concrete/ min. 125 - Aerated concrete 1 – Fire damper 2 – Solid ceiling construction 3 – Fire resistant board 4 –...
  • Page 41 ® NORDfire | FDMB 5.6 Installation outside solid ceiling construction Fig. 43 Outside solid ceiling construction - mineral wool - mortar and gypsum EIS 90 EIS 120 ****** ≤ 75** L=Min. 100 T=120 variabel**** T=60 L=Min. 400 T=120 Position: 1 – Fire damper 2 –...
  • Page 42 ® NORDfire | FDMB Fig. 44 Outside solid ceiling construction - Concrete EIS 90 Rebar - steel wire - Ø 6 mm ≤ 750 ≤ 100 Position: 1 – Fire damper * min 110 – Concrete/ min. 125 - Aerated concrete 2 –...

  • Page 43: Installation Frames

    ® NORDfire | FDMB Installation frames For dampers with A ≥ 800 and damper placement outside wall construction is necessary to use reinforcement Fig. 45 Fixing of reinforcement to damper body VRM 1. Insert part A, B on body of fire damper in correct position 2.

  • Page 44: Suspension Systems

    ® NORDfire | FDMB Suspension systems Fig. 47 Mounting to the ceiling wall Screw with internal Without anchor With anchor With hinge plate and and anchors thread and hexagon drive Hinge plates Screw with Internal thread and hexagon drive Load capacities of threaded hanger rods...
  • Page 45 ® NORDfire | FDMB 7.1 Horizontal installation Damper assembly procedures must be done so as all load transfer from the fire separating constructions to the damper body is absolutely excluded. Back-to-back air-conditioning piping must be hung or supported so as all load transfer from the back-to-back piping to the damper is absolutely excluded.
  • Page 46 ® NORDfire | FDMB 7.2 Vertical installation The damper must not be suspended or anchored. The duct must be anchored after national rules, like in fig. 85 - as an example. It can be suspended by using threaded rods and a mounting profiles. Load the suspension system depend on weight of the fire damper.
  • Page 47 ® NORDfire | FDMB 7.3 Rectangular fire damper suspension on the wall - horizontal installation Fire dampers installed remote from the wall must be suspended. The duct must be suspended on both sides of damper after national rules. Duct between fire damper and fire separating construction must be suspended by using threaded rods andmounting profiles, or another anchoring system according national standards.

  • Page 48: Pressure Loss

    ® NORDfire | FDMB Technical data Pressure loss ξ 8.1 Pressure loss calculation ∆p = ξ * ρ * (v / 2) presure loss (Pa) ∆p ξ coefficient of local pressure loss for the nominal damper section (see Tab. 5) ρ...

  • Page 49: Noise Data

    ® NORDfire | FDMB 1000 – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –...
  • Page 50 ® NORDfire | FDMB 9.3 Table of acoustics values Tab. 6. Level of accoustic output LW1 [dB] related to the 1 m section ξ (-) (m/s) 15,5 18,7 20,9 22,6 25,2 26,3 27,2 31,2 33,4 35,1 36,5 38,8 40,5 26,1...

  • Page 51: Material, Finishing

    ® NORDfire | FDMB 10. Material, finishing 10.1 Material - Damper bodies are supplied in the design made of galvanized plate without any other surface finishing. - Damper blades are made of fire resistant asbestos free boards made of mineral fibres.

  • Page 52: Transportation And Storage

    ® NORDfire | FDMB 12. Transportation and storage 12.1 Transport Dampers are delivered loose. Other packing methods must be agreed with the manufacturer in advance. If packaging is used, they are not subject to return and their price is not included in the product price.
  • Page 53 ® NORDfire | FDMB All effective safety standards and directives must be observed during fire damper assembly. It is recommended to provide periodical checks, maintenance and service actions on Fire Equipment by Authorized persons. The authorized persons can be trained by Producer, or by authorized Distributor.

  • Page 54: Spare Parts

    ® NORDfire | FDMB 15. Spare parts - Spare parts are supplied only on basis of an order. - Control for square damper and round damper is identical. 16. Restore function of actuating mechanism after fuses initiation - If fuse Tf1 is initiated (duct outside temperature) than is necessary to change thermoelectrical starting mechanism BAT72B-S.
  • Page 55 ® NORDfire | FDMB 17.3 Reinforcement - damper placement outside wall or ceiling construction A x B Type Nominal size Example: VRM 800x400 17.4 Data label is placed on the damper body. MANDÍK, a.s. Dobříšská 550, 267 24 Hostomice, Czech Republic...
  • Page 56 ETS NORD AS Address: Peterburi tee 53 11415 Tallinn Estonia Phone: +372 680 7360 info@etsnord.ee www.etsnord.ee ETS NORD Finland Address: Pakkasraitti 4 04360 Tuusula Finland Phone: +358 0401 842 842 info@etsnord.fi www.etsnord.fi ETS NORD Sweden Address: Järsjögatan 7 69235 Kumla...
