ETS NORD NORDfire FDMB Manual

Square dampers from 160×160 mm to 0,5 m2 (max. dimensions 1000×500 mm)
Hide thumbs

Advertisement

Quick Links

Download this manual
NORDfire
FDMB Fire Damper
Square dampers from 160×160 mm to 0,5 m2 (max. dimensions 1000×500 mm)
CE certified acc. to EN15650
Fire resistance up to EIS 120
External Casig leakage class C, Internal leakage class 2 acc. to EN 1751
Damper actuating mechanical, or electrical

Advertisement

loading
Need help?

Need help?

Do you have a question about the NORDfire FDMB and is the answer not in the manual?

Questions and answers

Related Manuals for ETS NORD NORDfire FDMB

Summary of Contents for ETS NORD NORDfire FDMB

  • Page 1 NORDfire FDMB Fire Damper Square dampers from 160×160 mm to 0,5 m2 (max. dimensions 1000×500 mm) CE certified acc. to EN15650 Fire resistance up to EIS 120 External Casig leakage class C, Internal leakage class 2 acc. to EN 1751 Damper actuating mechanical, or electrical...
  • Page 2 ® NORDfire | FDMB General information Description 1.1 Fire dampers are shutters in ducts of air-conditioning devices that prevent spreading the fire and combustion products from one fire segment to the other one by means of closing the duct in the points of fire separating constructions.
  • Page 3 ® NORDfire | FDMB 1.3 Working conditions Right damper function is secured under the following conditions: Maximum air circulation speed: 12 m/s Maximum pressure difference: 1200 Pa The air circulation in the whole damper section must be secured as steady on whole surface.
  • Page 4 ® NORDfire | FDMB Design .80 Design .01 with mechanical control can be complemented with a terminal switches signaling of the damper blade position “CLOSED” and “OPEN”. Limit switches are connected via damper casing, cables are connected directly to limit switches. Fig.
  • Page 5 ® NORDfire | FDMB 2.2 Design with actuating mechanism Design .40, .50 The damper are equipped by Belimo actuators with spring return and thermoelectric activation device of BFL, BFN or BF depending on the damper size (furher mentioned as „actuators“). After being connected to power supply AC/DC 24V or 230V, the actuating mechanism displaces the damper blade into operation position ”OPEN”...
  • Page 6 ® NORDfire | FDMB Fig. 10 Actuating mechanism BELIMO BFL BFL (BFN) 230-T AC/DC 24 Tab 2.2.1. Actuating mechanism BELIMO BFL24-T(-ST), BFN 24-T(-ST), BFL 230-T a BFN 230-T Actuating mechanism BELIMO BFL, BFN 230-T BFL, BFN 24-T(-ST) AC 24 V 50/60 Hz Nominal voltage AC 230 V 50/60 Hz DC 24 V...
  • Page 7 ® NORDfire | FDMB Tab 2.2.2. Actuating mechanism BELIMO BFL24-TN(-ST), BF 230-TN Actuating mechanism BELIMO BF 24-TN(-ST) BF 230-TN AC 24 V 50/60 Hz Nominal voltage AC 230 V 50/60 Hz DC 24 V Power consumption - motoring - holding Dimensioning 10 VA (Imax 8,3 A @ 5 ms) 12,5 VA (Imax 500 mA @ 5 ms)
  • Page 8 ® NORDfire | FDMB Dimensions, weighs and effective area 3.1 Dimensions Fig. 23 Design with mechanical control Position: 1- Damper casing 2- Mechanics 3- Damper blade 4- Inspection hole covering 5- Sensor sticker 6- Hole for camera * X=23 (AxB≤500x400) * X=36 (AxB>500x400) Fig.
  • Page 9 ® NORDfire | FDMB 3.2 Dimensions, weights and effective area Tab 3.2.1. Dimensions, weights and effective area weight effect. Actu. Mech. A x B [mm] a [mm] c [mm] design area mech. contr. Sef. [m²] mech [kg] servo [kg] 160 x 160 0,0113 x 180 0,0137...
  • Page 10 ® NORDfire | FDMB weight effect. Actu. Mech. A x B [mm] a [mm] c [mm] design area mech. contr. Sef. [m²] mech [kg] servo [kg] 200 x 315 97,5 0,0398 x 355 117,5 10,5 0,0463 x 400 11,0 0,0535 x 450 10,0 13,0...
  • Page 11 ® NORDfire | FDMB weight effect. Actu. Mech. A x B [mm] a [mm] c [mm] design area mech. contr. Sef. [m²] mech [kg] servo [kg] 250 x 600 13,0 16,0 0,1016 x 630 13,5 16,5 0,1075 x 650 13,5 16,5 0,1115 x 700...
  • Page 12 ® NORDfire | FDMB weight effect. Actu. Mech. A x B [mm] a [mm] c [mm] design area mech. contr. Sef. [m²] mech [kg] servo [kg] 315 x 180 10,5 0,0308 x 200 11,0 0,0363 x 225 52,5 11,5 0,0432 x 250 10,0 12,0...
  • Page 13 ® NORDfire | FDMB weight effect. Actu. Mech. A x B [mm] a [mm] c [mm] design area mech. contr. Sef. [m²] mech [kg] servo [kg] 400 x 500 14,5 17,5 0,1437 x 550 15,5 18,5 0,1611 x 560 15,5 18,5 0,1646 x 600...
  • Page 14 ® NORDfire | FDMB weight effect. Actu. Mech. A x B [mm] a [mm] c [mm] design area mech. contr. Sef. [m²] mech [kg] servo [kg] 500 x 750 21,0 24,0 0,2970 x 800 22,0 25,0 0,3194 x 900 24,0 27,0 0,3642 x 1000...
  • Page 15 ® NORDfire | FDMB weight effect. Actu. Mech. A x B [mm] a [mm] c [mm] design area mech. contr. Sef. [m²] mech [kg] servo [kg] 600 x 315 97,5 14,0 17,0 0,1249 x 355 117,5 15,0 18,0 0,1469 x 400 16,0 18,0 0,1715...
  • Page 16 ® NORDfire | FDMB weight effect. Actu. Mech. A x B [mm] a [mm] c [mm] design area mech. contr. Sef. [m²] mech [kg] servo [kg] 650 x 750 24,5 27,5 0,3965 700 x 160 11,5 14,5 0,0473 x 180 12,0 15,0 0,0603...
  • Page 17 ® NORDfire | FDMB weight effect. Actu. Mech. A x B [mm] a [mm] c [mm] design area mech. contr. Sef. [m²] mech [kg] servo [kg] 750 x 630 24,0 27,0 0,3790 x 650 24,5 27,5 0,3930 800 x 160 12,5 15,5 0,0546...
  • Page 18 ® NORDfire | FDMB 3.3 Blades overlaps Tab 3.3.1. Blades overlaps Blades overlaps Dimension Overlaps Act. mechanism side ”a” Tab. 4.2.1 Blades overlaps Fig.28 Side without act. mechanism ”c” Tab. 4.2.1 These values have to respected when projecting related air-conditioning Fig.
  • Page 19 ® NORDfire | FDMB Placement and Assembly 4.1 Fire dampers are suitable for installation in arbitrary position in vertical and horizontal passages of fire separating constructions. Damper assembly procedures must be done so as all load transfer from the fire separating constructions to the damper body is absolutely excluded. Back-to-back air-conditioning piping must be hung or supported so as all load transfer from the back-to-back piping to the damper is absolutely excluded.
  • Page 20 ® NORDfire | FDMB Fig. 28 Built in edge “Wall edge sticker” indicates the recommended edge of installation of fire damper into the fire partition structure (wall). The damper must be installed so that the entire damper blade - in the closed position - is located inside the fire separating structure (wall) and at the same time the control mechanism and inspection openings are freely accessible.
  • Page 21 ® NORDfire | FDMB Statement of installations 5.1 Installation method list Tab 5.1.1.Installation method list Wall/Ceiling Fire Fire separating constru. Installation Page Min.thickness resist. [mm] EIS 120 Mortar or gypsum EIS 90 Stuffing box with fire protection EIS 60 mastic EIS 60 Fire protection foam with stucco EIS 45...
  • Page 22 ® NORDfire | FDMB 5.2 Installation in solid wall construction Fig. 30 Solid wall construction- mortar or gypsum EIS 120 ≥ 100 EIS 90 ≥ 50* * Around the perimeter * Around the perimeter Position: 1 Fire damper 2 Solid wall construction 3 Mortar or gypsum 4 Duct Shown schemes of incorporation and damper are illustrative only!
  • Page 23 ® NORDfire | FDMB Fig. 32 Solid wall construction- fire protection foam with stucco plaster Maximal damper dimensions 400x400 mm EIS 60 EIS 45 EIS 30 Position: Fire damper Solid wall construction Fire protection foam Stucco plaster Duct Used materials - example:* HILTI CFS-F FX - EIS 60 PROMAFOAM-C - EIS 45 SOUDAL, Soudafoam FR-B1 - EIS 30...
  • Page 24 ® NORDfire | FDMB Fig. 33 Solid wall construction- battery- mortar or gypsum The gap 94 mm between dampers can be filled by mineral stone wool min. density 140 kg/m³. Wool is fixed to damper body by fire protection mastic. The gap 94 mm between dampers can be filled by mineral stone wool min.
  • Page 25 ® NORDfire | FDMB Fig. 34 Solid wall construction- installation next to wall, ceiling- mortar or gypsum and mineral wool. Notice: • Gap between damper and construction is filled by mortar or gypsum and mineral wool • Wool is fixed to damper body and construction by fire protection mastic •...
  • Page 26 ® NORDfire | FDMB Fig. 35 Solid wall construction- stuffing box, fire protection mastic and cement lime plate EIS 90 * Around the perimeter Screws has to be fixed in wall/ ceiling construction. (If it is needed use steel bracket). Position: 1 Fire damper 2 Solid wall construction...
  • Page 27 ® NORDfire | FDMB Fig. 36 Solid wall construction- Weichschott EIS 90 Position: 1 Fire damper 2 Solid wall construction 3 Fire resistant board 4 Fire stop coating thickness 1 mm 5 Duct Used materials - example:* Hilti CFS-CT B 1S 140/50 Hilti CFS-CT ** Fire resistant insulation and fire resistant board can be replaced by another approved fire sealing system for damper installation with equivalent material properties.
  • Page 28 ® NORDfire | FDMB 5.3 Installation outside solid wall construction Fig. 37 Outside solid wall construction- mineral wool- mortar or gypsum EIS 60 * Around the perimeter Position: 1 Fire damper 2 Solid wall construction 3 Mortar or gypsum 4 Stone wool with wired mat on one side, density 66 kg/m³ 5 Duct Used materials - example:** Isover Ultimate Protect SLAB 4.0, th.
  • Page 29 ® NORDfire | FDMB Fig. 38 Outside solid wall construction- mineral wool- stuffing box and protection mastic EIS 60 * Around the perimeter Position: Fire damper Solid wall construction Stuffing box (mineral stone wool min. density 150 kg/m³) Fire protection mastic min. thickness 1 mm Stone wool with wired mat on one side, density 66 kg/m³...
  • Page 30 ® NORDfire | FDMB Fig. 39 Outside solid wall construction- mineral wool, stuffing box, fire protection mastic and cement lime plate. EIS 90 EIS 120 ***** * Around the perimeter Screws has to be fixed in wall/ ceiling construction. (If it is needed use steel bracket). Position: Fire damper Solid wall construction...
  • Page 31 ® NORDfire | FDMB 5.4 Installation in gypsum wall construction Fig. 41 Gypsum wall construction- mortar or gypsum EIS 120 EIS 90 Installation opening has to be reinforced by profile (UW, CW). Profil is fixed by screws ≥3,5 mm with corresponding length.
  • Page 32 ® NORDfire | FDMB Fig. 42 Gypsum wall construction- stuffing box and fire protection mastic EIS 60 Installation opening has to be reinforced by profile (UW, CW). Profil is fixed by screws ≥3,5 mm with corresponding length. Distance between screws ≤200 mm. Position: 1 Fire damper 2 Gypsum plate...
  • Page 33 ® NORDfire | FDMB Fig. 43 Gypsum wall construction- fire protection foam with stucco plaster Maximum damper dimensions 400x400 mm EIS 60 EIS 45 EIS 30 Installation opening has to be reinforced by profile (UW, CW). Profil is fixed by screws ≥3,5 mm with corresponding length.
  • Page 34 ® NORDfire | FDMB Fig. 44 Gypsum wall construction- battery- mortar or gypsum EIS 90 The gap 94 mm between dampers can be filled by mineral stone wool min. density 140 kg/m³. Wool is fixed to damper body by fire protection mastic. Installation opening has to be reinforced by profile (UW, CW).
  • Page 35 ® NORDfire | FDMB Fig. 45 Gypsum wall construction- installation next to wall, ceiling- mortar or gypsum and mineral wool EIS 90 Installation opening has to be reinforced by profile (UW, CW). Profil is fixed by screws ≥3,5 mm with corresponding length. Distance between screws ≤200 mm.
  • Page 36 ® NORDfire | FDMB Fig. 46 Gypsum wall construction- stuffing box, fire protection mastic and cement lime plate EIS 90 Installation opening has to be reinforced by profile (UW, CW). Profil is fixed by screws ≥3,5 mm with corresponding length. Distance between screws ≤200 mm.
  • Page 37 ® NORDfire | FDMB Fig. 47 Gypsum wall construction- Weichschott EIS 90 Installation opening has to be reinforced by profile (UW, CW). rofil is fixed by screws ≥3,5 mm with corresponding length. Distance between screws ≤200 mm. Position: 1 Fire damper 2 Gypsum plate 3 Mineral wool (type depending on the type of construction) 4 Fire resistant board...
  • Page 38 ® NORDfire | FDMB 5.5 Installation outside gypsum wall construction Fig. 48 Outside gypsum wall construction- mineral wool- mortar or gypsum EIS 60 Installation opening has to be reinforced by profile (UW, CW). Profil is fixed by screws ≥3,5 mm with corresponding length. Distance between screws ≤200 mm.
  • Page 39 ® NORDfire | FDMB Fig. 49 Outside gypsum wall construction- mineral wool- stuffing box and fire protection mastic EIS 60 Installation opening has to be reinforced by profile (UW, CW). Profil is fixed by screws ≥3,5 mm with corresponding length. Distance between screws ≤200 mm. Position: 1 Fire damper 2 Gypsum plate...
  • Page 40 ® NORDfire | FDMB Fig. 50 Outside gypsum wall construction- mineral wool- stuffing box and fire protection mastic and cement plate EIS 90 EIS 120 ***** Installation opening has to be reinforced by profile (UW, CW). Profil is fixed by screws ≥3,5 mm with corresponding length.
  • Page 41 ® NORDfire | FDMB Used materials - example:** 4 Promapyr. Rockwool Steprock HD. Hilti CFS-CT C 1S 140/50 5 Promastop - P, K, Hilti CFS-CT 6 Promatect - H 7 Rockwool Conlit Ductrock EIS 90, th. 60 mm Stuffing box, fire protection mastic, cement lime plate and insulation materials can be replaced by another approved fire sealing system for damper installation with equivalent material properties.

  • Page 42: Table Of Contents

    ® NORDfire | FDMB 5.6 Installation in solid ceiling construction Fig. 51 Solid ceiling construction- mortar or gypsum EIS 120 EIS 90 Position: 1 Fire damper 2 Solid ceiling construction 3 Mortar or gypsum * min. 110 - Concrete/ min. 125 - Aerated concrete 4 Duct ** Around the perimeter Shown schemes of incorporation and damper are illustrative only!

  • Page 43: Fire Damper

    ® NORDfire | FDMB Fig. 53 Solid ceiling construction- stuffing box, fire protection mastic EIS 60 Position: 1 Fire damper 2 Solid ceiling construction 3 Stuffing box (mineral stone wool min. density 140 kg/m³) 4 Fire protection mastic min. thickness 1 mm 5 Duct Used materials - example:** 3 Promapyr, Rockwool Steprock HD, Hilti CFS-CT B 1S 140/50...

  • Page 44: Mortar Or Gypsum

    ® NORDfire | FDMB Fig. 54 Solid ceiling construction- battery- mortar or gypsum EIS 90 The gap 94 mm between dampers can be filled by mineral stone wool min. density 140 kg/m³. Wool is fixed to damper body by fire protection mastic.

  • Page 45: Duct

    ® NORDfire | FDMB Fig. 55 Solid ceiling construction- stuffing box, fire protection mastic and cement lime plate EIS 90 Screws has to be fixed in wall/ceiling construction. (If it is needed use steel bracket). Position: * min. 110 - Concrete/ min. 125 - Aerated concrete 1 Fire damper ** Around the perimeter 2 Solid ceiling construction...
  • Page 46 ® NORDfire | FDMB Fig. 56 Solid ceiling construction- Weichschott EIS 90 Position: * min. 110 - Concrete/ min. 125 - Aerated concrete 1 Fire damper 2 Solid ceiling construction 3 Fire resistant board 4 Fire stop coating thickness 1 mm 5 Duct Used materials - example:** 3 Hilti CFS-CT B 1S 140/50...
  • Page 47 ® NORDfire | FDMB 5.7 Installation outside solid ceiling construction Fig. 57 Outside solid ceiling construction- mineral wool- mortar and gypsum EIS 90 EIS 120 ****** Position: * min. 110 - Concrete/ min. 125 - Aerated concrete 1 Fire damper 2 Solid ceiling construction Used materials - example:** 3 Mortar or gypsum...
  • Page 48 ® NORDfire | FDMB Fig. 58 Outside solid ceiling construction- Concrete EIS 90 Rebar- steel wire- Ø 6 mm Position: * min. 110 - Concrete/ min. 125 - Aerated concrete 1 Fire damper ** Around the perimeter 2 Solid ceiling construction 3 Concrete B20 4 Rebar 5 Duct...
  • Page 49 ® NORDfire | FDMB Installation frames Fig. 59 Fixing of reinforcement to damper body VRM Important: For lower resistance that EI90 the reinforcement VRM is not necessary! 1. Insert part A, B on body of fire damper in correct position 2.
  • Page 50 ® NORDfire | FDMB Suspension systems Fig. 60 Mounting to the ceiling wall Without anchor With anchor With hinge plate and and anchors Hinge plates Position: 1 Threaded rod M8 – M20 2 Nut 3 Washer 4 Coupling Nut 5 Anchor 6 Hinge plate - min.
  • Page 51 ® NORDfire | FDMB 7.1 Horizontal installation Fire dampers can be suspended by using threaded rods and a mounting profiles. Load the suspension system depend on weight of the fire damper. Damper assembly procedures must be done so as all load transfer from the fire separating constructions to the damper body is absolutely excluded.
  • Page 52 ® NORDfire | FDMB 7.2 Vertical installation Fire dampers can be suspended by using threaded rods and a mounting profiles. Load the suspension system depend on weight of the fire damper. Damper can be suspended from the ceiling construction or supported above the ceiling construction.
  • Page 53 ® NORDfire | FDMB 7.3 Rectangular fire damper suspension on the wall- horizontal installation Duct between fire damper and fire separating construction can be suspended by using threaded rods and mounting profiles. Load the suspension system depend on weight of the fire damper and duct system.
  • Page 54 ® NORDfire | FDMB IX. Technical data Pressure loss 8.1 Pressure loss calculation [Pa] pressure lost m.s ] air flow speed in nominal damper section air density [kg.m ] coefficient of local pressure loss for the nominal damper section (see Tab. 11.1.1.) 8.2 Determination of pressure loss by using diagram =1,2 kg m Diagram 8.2.1.Pressure losses for air density...
  • Page 55 ® NORDfire | FDMB Coefficient of local pressure loss (-) 9.1 Coefficient of local pressure loss Tab 9.1.1. Coefficient of local pressure loss 4,771 3,458 2,717 2,285 1,813 1,538 1,407 1,327 1,165 1,040 2,025 1,874 4,102 3,251 2,351 2,016 1,676 1,342 1,221 1,136 0,986 0,922...
  • Page 56 ® NORDfire | FDMB 10. Noise data 10.1 Level of acoustic output corrected with filter A. level of acoustic output corrected with filter A level of acoustic output related to the 1 m² section (see Tab. 12.3.1.) duct cross section correction to the weight filter A (viz Tab.
  • Page 57 ® NORDfire | FDMB Tab 10.3.4. Relative level expressing the shape of the spectrum f [Hz] [m/s] 1000 2000 4000 8000 -4,5 -6,9 -10,9 -16,7 -24,1 -33,2 -43,9 -56,4 -3,9 -5,3 -8,4 -13,1 -19,5 -27,6 -37,4 -48,9 -3,9 -4,5 -6,9 -10,9 -16,7 -24,1...
  • Page 58 ® NORDfire | FDMB IX. Material, finishing 11. Material 11.1 Damper bodies are supplied in the design made of galvanized plate without any other surface finishing. Damper blades are made of fire resistant asbestos free boards made of mineral fibres. Control devices of dampers has cover from mechanically resistant and standing plastic and rest of the parts is galvanised without further surface treatment.
  • Page 59 ® NORDfire | FDMB IX. Inspection, testing 12. Inspection, testing 12.1 The appliance is constructed and preset by the manufacturer, its operation is dependent on proper installation and adjustment. IX. Transportation and storage 13. Logistic terms 13.1 Dampers are transported by box freight vehicles without direct weather impact, there must not occur any sharp shocks and ambient temperature must not exceed +40°C.
  • Page 60 ® NORDfire | FDMB 15. Entry into service and revisions 15.1 Before entering the dampers into operation after their assembly and by sequential checks, the following checks must be carried out. Visual inspection of proper damper integration , inside damper area, damper blade, contact surfaces and silicon sealing. Check of thermal protective fuse and closing mechanism.
  • Page 61 ® NORDfire | FDMB • There must be a release lever, which releases initiation lever of control and mechanism will displace to "CLOSED" position. • If not, you need to contact the manufacturer and order new mechanism. • Mechanism dimension is marked M1 to M4, according to internal forces of spring. 15.3 Before entering the dampers with actuating mechanism into operation after their assembly and by sequential checks and following checks must be carried out.
  • Page 62 ® NORDfire | FDMB IX. Ordering information 18. Ordering key 18.1 Fire damper If installation holders, installation frame or design for installation in Weichschott system are requested, it has to be mentioned separately in the order. Installation frame could be fixed to the damper body or supplied separately.
  • Page 63 ® NORDfire | FDMB IX. Product data 18.2 Data label is placed on the damper body. Kuvamateriaali on havainnollistava RDT-07-0121 Pidätämme oikeuden muutoksiin...
  • Page 64 ETS NORD Suomi Osoite: Pakkasraitti 4 04360 Tuusula Finland Puh: +358 0401 842 842 info@etsnord.fi www.etsnord.fi...
