Oracle Server X6-2 Getting Started Manual page 4

Power On the Server
Use the next figure to locate status indicators (LEDs) on the server front panel.
1 – SP OK LED
Connect the power cords to two separate power sources.
1.
The server can operate with one power source; however, using only one power source eliminates redundancy.
When the power cords are connected to the server's AC inlets and power sources, the following actions
occur:
The green AC OK power supply LEDs light.
■
While the Oracle ILOM SP initializes, the green SP OK LED flashes rapidly.
■
Once the Oracle ILOM SP has fully initialized, the SP OK LED is steady on and the green Power/OK
■
LED flashes slowly, indicating that the host is in Standby power mode.
In Standby power mode, the server is not initialized or powered on.
2. Press Enter on the terminal device to create a connection between the terminal and serial
console of the Oracle ILOM SP.
The Oracle ILOM Login prompt appears.
3.
Use the root user account and the password changeme to log in to Oracle ILOM.
host-name login: root
Password: changeme
The Oracle ILOM command-line interface (CLI) prompt (->) appears.
By default, the SP is configured to use DHCP to obtain an IP address. If you plan to assign a static IP address
to the SP, refer to the Oracle Server X6-2 Installation Guide.
For optimal security, change the root password when working in Oracle ILOM. For information about
administrative tasks such as changing passwords, adding accounts, and setting account privileges, refer to
the Oracle X6 Series Servers Administration Guide and the Oracle ILOM documentation at
oracle.com/goto/ilom/docs.
4. Power on the server and redirect the host output to display on the serial terminal device.
2 – Power/OK LED 3 – Power button
http://www.
4
