Northern Telecom QCA146 Installation And Testing Instructions page 55

Figure 3-10
P10 cable terminations and designations
To -52V
PFTU
Power
Connecting
Block
Red/Black
Pair
Braided Wire
Not Connected
(Ill553-1144)
To GND
To Shelf
On PFTU
Transfer
And On All
Consoles
PFTU
To Shelf
Transfer
On Assigned
PFTU
AUX GRD XPE XCE
Red White Black Black Black Black Red
Red/Black
White/Black
Pair
Cable 1
QCAD294 Cables
From Cabinet
2-Mb/s Remote Peripheral Equipment
To MJ Alarm
On Console
To Remote
Or External
Alarm Indicator
REMA REMB MJ
Pair
Braided Wire
Cable 2 Not Connected
Installation
Remaining Terminals
Can Be Used To Multiple
AUX And GRD Connections
White (Not Used)
White/Black
Pair
Appendix 1 to 553-2741-200
3-49
