Northern Telecom QCA146 Installation And Testing Instructions page 50

F i g u r e 3 - 9
Expansion battery unit connections
Black Wire
1 2
Green
Wire
W1
Inside View Of
Front Panel
QCAD301 Cable
From Expansion
QBL24 Unit
DC
BRKR
Connects
To Cabinet
(Ill553-1138)
1
8
1
2
7
2
3
6 3
4
5 4
TB1
5
Red Wire
SEN
+ +
-
QBL24
BATT UN
54V/30A
QCAD295 Battery Cable
2-Mb/s Remote Peripheral Equipment
Shield
Expansion QBL24
Battery Unit
Main QBL24
Battery Unit
Remove Plug
To Insert 90°
Elbow And Cable
Flexible Conduit
5.5 ft (1675 mm)
in Length
Installation
DC
BRKR
SEN
+ +
-
QBL24
BATT UN
54V/30A
QCAD301
Expansion Cable
Appendix 1 to 553-2741-200
3-43
