This operation and maintenance manual has to be handed over to the owner/user after putting the
© July 2005 by Rotary Lift.
Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005
SL135
Capacity: 3500 kg
Model
SL135RA
SL135HP
SL135HMP
Initial operation:
lift into operation.
Serial Number
PBxxxxx
Rev.C 01/07/05
O
P
E
R
A
T
I
O
N
&
M
A
I
N
T
E
N
A
N
C
E
M
A
N
U
A
L
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rotary SL135
Summary of Contents for Rotary SL135
- Page 1 This operation and maintenance manual has to be handed over to the owner/user after putting the lift into operation. © July 2005 by Rotary Lift. PBxxxxx Rev.C 01/07/05 Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005...
-
Page 2: Table Of Contents
They have to be engaged by the person responsible expressly to operate the lifting platform. Display this manual in a conspicuous location in the area convenient to the operator. Operation and maintenance manual • ROTARY inground lifts SmartLift • Rev. B • Release: 08/2004... -
Page 3: Control Box
5. There is no pneumatic lowering system in case of power failure. Lifting or lowering is limited mechanically by an upper and lower stop. You have to release the level immediately at the upper or lower mechanical stop. Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005... -
Page 4: Certificate For Initial Operation By An Expert
Place, Date Signature of the expert Name and adress of the expert Adress of the owner (stamp): By fax to ++49-(0)-771/9233-99 BlitzRotary GmbH Hüfinger Str. 55 78199 Bräunlingen GERMANY Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005... -
Page 5: Certificate For Power Connection By An Electro-Technician
Place, Date Signature of the electro-technician Name of the electro-technician Adress / Stamp of the electro-technician´s company Please note: Only the owner is responsible for the regular power connection! Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005... -
Page 6: Indications For Regular Maintenance
12. Check the valve plugs for humidity! If necessary protect with a hydrophobic grease. 13. Renew damaged rubber profile! Use silicone at the contacts of two profiles! 14. Inform the responsible person about special observations! 15. Complete the maintenance manual! Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005... -
Page 7: Results Of The Regular Maintenance
You will find some tips for the carrying out of this yearly check and maintenance at chapter 5. Necessary repairs can be carried out against separate charge. Date Results of check Name and adress of the expert Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005... -
Page 8: Technical Data Sheet
Not for staying below the load-carrier. Not for staying on the load-carrier. Not for use as a lift bridge. Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005... -
Page 9: Complete User Instructions
They have to be engaged by the person responsible (business employer, workshop master or security representative) expressly to operate the lifting platform. The tips of the abridged operating instructions at the control box are to observe. Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005... - Page 10 It is not allowed to set the lift and the vehicle swinging intentionally. k) During lifting and lowering of the lift no persons are allowed to stay in the danger spot of the lift. Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005...
- Page 11 At vehicles with low clearance height of the vehicles´s bottom please note not to damage the vehicle when driving on or lifting by the support plate. Probably it is necessary to use different screw-in cups or cup elongations to avoid this. Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005...
- Page 12 Please use them analogous to the normal supports. Aditionally you have to adjust the cross plate. For driving over you have to push in the cross plate of the supports! Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005...
- Page 13 8.6 Maintenance, care and examination The lifting platform is in general maintenance-free for the operator provided that the regular annual examination of an authorized ROTARY service technician is carried out together with a maintenance. Otherwise we refer to maintenance instructions (see capter 5.)!
- Page 14 8.9 Spare parts For repairs, only original ROTARY spare parts are allowed. These can be bought over ROTARY service technicians or in case of smaller self repairs directly from ROTARY.
-
Page 15: Ec-Conformity Declaration
"Scope of application" of this operation manual or if any modifications or changes whatever are made to the machine without prior approval from our end. Bräunlingen, 01th of July 2005 F. Scherer General Manager Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005...
