Introduction ........................................................................ 2
Owner/Employer Responsibilities .................................... 3
Safety Instructions ............................................................. 4
Operating Instructions ...................................................... 6
Maintenance Instructions.................................................. 10
Trouble Shooting ................................................................ 11
Manual Lowering of Lift ..................................................... 14
Date and Time Setting ....................................................... 16
Timer and Alarm Setting .................................................... 17
Rotary Contact Information ............................................... 18
Change Language .............................................................. 19
Installer: Please return this booklet to literature package and give to lift owner/operator.
© January 2003 by Rotary Lift.
SL29i/SL212i
(400 Series)
SL29i Capacity 9,000 lbs.
SL212i Capacity 12,000 lbs.
Table Of Contents
LP20089
O
O
P
P
E
E
R
R
A
A
T
T
I
I
O
O
N
N
&
&
M
M
A
A
I
I
N
N
T
T
E
E
N
N
A
A
N
N
C
C
E
E
M
M
A
A
N
N
U
U
A
A
L
L
OM20120
Rev. B 01/28/03
Advertisement
Table of Contents
Related Manuals for Rotary SL212i 400 Series
Summary of Contents for Rotary SL212i 400 Series
-
Page 1: Table Of Contents
Date and Time Setting ............16 Timer and Alarm Setting ............ 17 Rotary Contact Information ..........18 Change Language .............. 19 Installer: Please return this booklet to literature package and give to lift owner/operator. LP20089 OM20120 © January 2003 by Rotary Lift. Rev. B 01/28/03... -
Page 2: Introduction
INTRODUCTION The Rotary inbay technology lift represents a technological advancement that brings the power of information right into the service bay. • Bay management tools include owner and operator instructions, maintenance reminders, troubleshooting tips, date and time display and illustrated pickup points. -
Page 3: Owner/Employer Responsibilities
OWNER/EMPLOYER RESPONSIBILITIES The Owner/Employer: • Shall ensure that lift operators are qualified and that they are trained in the safe use and operation of the lift using the manufacturer’s operating instructions; ALI/SM 93-1, ALI Lifting it Right safety manual; ALI/ST-90 ALI Safety Tips card;... -
Page 4: Safety Instructions
• Daily inspect your lift. Never operate if it malfunctions or if it has broken or damaged parts. Use only qualified lift service SAFETY SAFETY personnel and genuine Rotary parts to make repairs. INSTRUCTIONS INSTRUCTIONS • Thoroughly train all employees in use and care of lift, using manufacturer’s instructions and Lifting It Right and Safety... - Page 5 SAFETY INSTRUCTIONS WARNING WARNING WARNING Use height extenders Remain clear of lift Use vehicle Clear area if vehicle when necessary Keep feet when raising or manufacturer’s is in danger of falling. to ensure clear of lift lowering vehicle. lift points. good contact.
-
Page 6: Operating Instructions
OPERATING INSTRUCTIONS To avoid personal injury and/or property damage, permit only trained personnel to WARNING operate lift. After reviewing these instructions, get familiar with lift controls by running the lift through a few cycles before loading vehicle on lift. Always lift the vehicle using all four adapters. NEVER raise just one end, one corner, or IMPORTANT one side of vehicle. - Page 7 ypical Lifting Points Three Position Flip-up Adapter LIFT LIFT POINTS POINTS Stub Frame Perimeter Frame Unitized Body Pickup Truck Fig. 3 Unitized Body LIFT LIFT POINTS POINTS Unitized Body Pickup Truck Stub Frame Perimeter Frame Fig. 4 Adjustable Screw/Pad Adapter NOTE: Some vehicles may have the manufacturer's Service Garage Lift Point locations identified by triangle shape marks on it's undercarriage (reference ANSI/SAE J2184-1992).
- Page 8 6. To Raise Lift: A. Push on the touch pad, Fig. 6. Raise lift until vehicle tires clear the floor. Check Adapter Contact: Stop and check adapters for secure contact at vehicle manufacturer’s recommended lift points, Fig. 3 and Fig. 4. B.
- Page 9 8. To Lower Lift: A. Remove all tools or other objects from lift area. SAFETY WARNING INSTRUCTIONS B. Raise lift off locking latches by pushing touchpad. C. Press on touchpad to lower lift. Proper maintenance Keep feet and inspection clear of lift is necessary while lowering.
-
Page 10: Maintenance Instructions
Dexron III ATF or ISOVG32 Hydraulic Fluid. Replace all caution, warning or safety related decals on the lift if unable to read or missing. Reorder labels from Rotary Lift, see Do not override DO NOT remove oil... -
Page 11: Trouble Shooting
1. Contact authorized Rotary POWER UNIT CIRCUIT FAULT repairperson. No error message on LCD 1. Touch pad defect 1. Contact your Authorized Rotary repair person. Motor does not run. 1. Replace blown fuse or reset circuit 1. Blown fuse or circuit breaker. - Page 12 1. Liquid detected in containment Liquid Detected In Containment 2. Remove all liquid from lift contain- ment. 3. Call a Rotary Authorized Installer for assistance if needed. 4. Press mode button again to resume lift operation. 5. Inbay liquid detection system screen will display until lift containment has been emptied of liquid.
- Page 13 Trouble Cause Remedy Liquid Detected In Containment Error Message on LCD (No Liquid Found In Containment) 1. Call a Rotary Authorized Installer 1. Possible Causes (Pressure Sensor Fault) for assistance. 2. Fault: Plugged or kinked sensor tube. Fix: Check by removing air connec tion to pressure sensor.
-
Page 14: Manual Lowering Of Lift
Fig. 8. 8. If your facility power was not lost have a certified electrican check wiring to lift or call an authorized Rotary repair person. - Page 15 Press Button On Top Of a Air Valve to release locks. DO NOT Use A Sharp Object It May Damage The Valve. (#2)1/4" Air Line To 1/4" Exhuast Air Line Male Run Tee Attached To Coupling 1/4" Air Line From On Lift Frame Reducing Male Branch Tee To Inline Regulator...
-
Page 16: Date And Time Setting
DATE AND TIME SETTING (USER PROFILE) inbay Master Control Panel Raise Lift/Scroll Up Mode Button Lower Lift/Scroll Down Main Selection/Lower to Locks To set clock DATE: To set clock TIME: 1. Ensure Power-Up Lift Switch is ON SELECT 1. Press on touchpad for TIME 2. -
Page 17: Timer And Alarm Setting
TIMER AND ALARM SETTING (USER PROFILE) inbay Master Control Panel Raise Lift/Scroll Up Mode Button Lower Lift/Scroll Down Main Selection/Lower to Locks For ALARM Settings: For TIMER Settings: 1. Return to TIMER/ALARM menu 1. Turn Power Up Lift Switch ON 2. -
Page 18: Rotary Contact Information
2. Press Mode Button to inbay Technology menu 3. Press on touchpad to ROTARY INFORMATION SELECT 4. Press on touchpad to principal Rotary Lift contacts, i.e. LOWER TO LOCKS U.S., Canada, International 5. Press on touchpad to appropriate contact, i.e. U.S. -
Page 19: Change Language
CHANGING LANGUAGE If lift is not operating properly, DO NOT use until adjustments or repairs are made by qualified lift service personnel. To avoid personal injury, permit only qualified personnel to perform maintenance on these lifts. inbay Master Control Panel Raise Lift/Scroll Up Mode Button Lower Lift/Scroll Down... - Page 20 Replacement Parts: See installers package for parts breakdown sheet. Order Genuine Rotary replacement parts from your nearest Authorized Parts Distributor. Maintenance Assistance: Contact your local Rotary distributor. Should further assistance be required, contact Rotary Lift, at one of the phone numbers listed below. World Headquarters: Italy:...
