User Manual
Annex Manager R3.0 Release Notes
A
nnex Manager is an SNMP-based management application that uses
the X Windows/Motif graphical user interface. Annex Manager is
specifically designed to manage Bay Networks Remote Access Servers,
and is not intended as a general purpose network manager. While Annex
Manager can detect SNMP devices that are not Annexes, you can not use
it to configure a non-Annex device. Annex Manager R3.0 runs on a
workstation platform running BSD Unix (SUN Sparc, HP, RS/6000). The
user interface is built to the X Windows/Motif standard. Annex Manager
is designed to run stand-alone and contains all the necessary SNMP
protocol routines and X Windows/Motif binary libraries. The installation
process copies the appropriate binary executable and all associated help
and data files from the distribution media onto the workstation's disk
store. Annex Manager can be loosely coupled with several standard
network management products such as SunNet Manager, HP/Openview,
or Netview for IBM AIX. Annex Manager does not use the API interfaces
provided by those products.
Why Use Annex Manager?
Annex Manager allows a system administrator to monitor and configure
Annexes in a network. Annex Manager is a host based, window oriented,
configuration and management application. The displays and user
interface conform to the X Windows/Motif standard. Annex Manager
works best with a color monitor directly attached to a workstation or a
color X Windows terminal connected to a networked UNIX host. In
addition, it supports a grey-scale X Windows terminal attached to a
workstation.
Annex Manager's configuration tool is easy to learn and use. It supports
the functionality of the older host-based NA configuration tool in an easier
to use format. Annex Manager is specifically designed to configure and
manage Annex products. Its features depend on the proprietary MIB
defined for the Annex and on the various standard MIBs supported by the
Annex. Therefore, Annex Manager cannot manage other SNMP
166-025-511
Rev. C
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Nortel Manager
Summary of Contents for Nortel Manager
- Page 1 Bay Networks Remote Access Servers, and is not intended as a general purpose network manager. While Annex Manager can detect SNMP devices that are not Annexes, you can not use it to configure a non-Annex device. Annex Manager R3.0 runs on a workstation platform running BSD Unix (SUN Sparc, HP, RS/6000).
- Page 2 Annex Manager R3.0 Release Notes networked nodes. It is not intended to be a generic SNMP management tool. Annex Manager provides features that have not been available with the NA utility. Users can: 166-025-511 • Configure Annexes in Setup or Customize mode.
- Page 3 Supported Annex Hardware Annex Manager R3.0 supports the following Remote Annex hardware running the specified Annex Software Release: Table 1. Supported Annex Hardware Hardware RA2000 RA4000 RA6100 5390 5391 5393 5399 RA6300 Annex 3 Micro Annex MicroCS Cabletron CSMIMII Cabletron CSMIMT1...
-
Page 4: System Requirements
Annex Manager. In all cases, a color monitor or X Windows terminal is recommended, although Annex Manager is usable with a monochrome X Windows terminal. - Page 5 Remote Display Requirements If you use Annex Manager on an X Windows terminal, we recommend that you have more than 2MB of RAM to avoid problems when you have multiple windows open simultaneously. New Features and Commands Annex Manager Release 3.0 now supports the newly released 5399. For more information on the new 5399 product features and commands, please see the Remote Annex Release 5.0.12 Release Notes and updated...
