- Page 1 L310 RFID 感應式門鎖 使用手冊 www.waferlock.com 通過 國際認證...
-
Page 2: Table Of Contents
WAFERLOCK CORPORATION Content ............ Specification ■ ............ Appearance ■ ............ Enroll Programming Card ■ ............ Lock Setup with App ■ STANDALONE MODE PROGRAMMING INSTRUCTION ............ Enroll New User Credentials ■ ............ Unlock with User Credentials ■ ............ Remove All User Credentials ■... -
Page 3: Specification
WAFERLOCK CORPORATION Specification ■ Front Escutcheon Dimension : 99.40 x 23.80 x 169.40mm ( W x T x H ) ■ Back Escutcheon Dimension : 99.40 x 23.80 x 169.40mm ( W x T x H ) ■ Access Solutions : Key Card / Passcode / App / Mechanical Key ■... -
Page 4: Appearance
WAFERLOCK CORPORATION Appearance Battery Slide Cover Key Pad AAA Battery X 4pcs Card Reading Area Wakeup Button Inside Lever Outside Lever Latch... - Page 5 Remark Before enrolling programming card, L310 is in construction mode and is able to operate by any Mifare card and default passcode 123456. If you hear 2 beeps / blue light blinks twice, it means the programming card enrollment failed.
-
Page 6: Lock Setup With App
WAFERLOCK CORPORATION Follow below steps to get your lock setup with App supported Lock Setup with App by WAFERKEY. You can also use the mobile App to set up your lock step-by-step and access installation videos. Step 1 Step 2... -
Page 7: Enroll New User Credentials
WAFERLOCK CORPORATION STANDALONE MODE PROGRAMMING INSTRUCTION WARNING Standalone Mode programming functions (Programming Card) are Please remember to enroll NOT available after the lock is paired with mobile App! If you would like Programming Card, referring to use Standalone Mode, please unpair the lock via WAFERKEY App. -
Page 8: Unlock With User Credentials
WAFERLOCK CORPORATION Unlock with User Credentials Remark Step 1 Step 2 Remark: When blue ligh blinks twice means the user credential has no access right. Present the user credential to The keypad led run clockwise reading area. when access granted. -
Page 9: Remove All User Credentials
WAFERLOCK CORPORATION Remove All User Credentials Step 1 Step 2 Step 3 Present the programming card Press “1” to enter the Press the “TOUCH” key, keypad to reading area, number 1, 2, programming mode, lights up and then press and 3 on keypad will blink with and blue light will blink. -
Page 10: Enroll New Passcode
WAFERLOCK CORPORATION Enroll New Passcode Step 1 Step 2 Step 3 Present the programming card Press “2” to enter the Key in only 6 digits passcode to reading area, number 1, 2, programming mode, and press # as end. and 3 on keypad will blink with and the keypad lights up. -
Page 11: Unlock With Passcode
WAFERLOCK CORPORATION Unlock with Passcode Step 1 Step 2 Remark When blue light blinks twice means the passcode has no access right. Keypad will be locked automatically for 3 minutes when passcode without access right has been entered 5 times. -
Page 12: Remove All Passcode
WAFERLOCK CORPORATION Remove All Passcode Step 1 Step 2 Step 3 Present the programming card Press “2” to enter the Press #. While a long to reading area, number 1, 2, programming mode, and the beep sound and blue light will and 3 on keypad will blink with keypad lights up. -
Page 13: Remove Individual Passcode
WAFERLOCK CORPORATION Remove Individual Passcode Step 1 Step 2 Step 3 Present the programming card Press “2” to enter the Key in the 6 digits passcode to reading area, number 1, 2, programming mode, you would like to remove, then and 3 on keypad will blink with and the keypad lights up. -
Page 14: Volume Setting
WAFERLOCK CORPORATION Volume Setting Step 1 Step 2 Step 3 Present the programming card Press “2” to enter the Press 2#, there will be 2 short to reading area, number 1, 2, programming mode, beep sounds. and 3 on keypad will blink with and the keypad lights up. -
Page 15: Program Door Opening And Closing Mode
WAFERLOCK CORPORATION Program Door Opening and Closing Mode Step 1 Step 2 Step 3 Present the programming card Press “2” to enter the Press 5#, there will be 2 short to reading area, number 1, 2, programming mode, beep sounds. -
Page 16: Passcode Anti-Peeping Setup
WAFERLOCK CORPORATION Passcode Anti-Peeping Setup Step 1 Step 2 Step 3 Present the programming card Press “2” to enter the Press 7#, there will be 2 short to reading area, number 1, 2, programming mode, beep sounds. and 3 on keypad will blink with and the keypad lights up. -
Page 17: Low Battery Warning
WAFERLOCK CORPORATION Low Battery Warning Step 1 Step 2 Step 3 Either when using credentials / passcode / mobile App to unlock or lock the door, or when using the programming card for enrollment, if there is 3 short beep sounds and appear 5 times, and blue light... -
Page 18: Reminder
WAFERLOCK CORPORATION Reminder 1. When the battery is low, credentials / passcode cannot be added or removed by programming card. 2. The credentials (including passcode) can be set up to maximum 2,000 sets. There will be 10 short beep sounds with blue light blinks 3 times when reaching maximum number. - Page 19 WAFERLOCK CORPORATION Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 20 維夫拉克股份有限公司 台 灣 研 發 製 造 文案內容本公司保有修改權利，產品以實物為主 客 服 專 線 : 0 8 0 0 - 0 0 2 - 3 4 5...
