L730
COMPACT
HANDLE LOCK
Installation Guide
Parts List
■
Outer Handle Set X 1
■
Inner Handle Set X 1
■
Lever Rose X 1
■
Fixing Screws X 2
■
Fixing Screws X 2
■
Spindle X 1
■
Hexagon Driver (#1.5) X 1
Hexagon Driver (#3.0) X 1
■
CR2 Lithium Battery X 1 (3V)
Battery Replacement
White strap
1
Remove the outer battery cover.
2
Remove two screws and inner battery
cover.
3
Insert CR2 battery and make sure the
white battery strap is properly under/cross
the battery. (It helps you remove the
battery easily).
You will see the green and red lights
alternately flashing 2 times.
If you do not see the light, please check
battery polarity (+/-) and try again.
4
Attach the inner battery cover and
tighten the two screws fully.
5
Attach the outer battery cover properly.
