2
Inside Assembly
3
Inner Lever
4
Backplate
Strike
6
7
Latch
L310 Parts List
5
Rubber Gasket X1
8
M3 Screws (Black) X 3
9
M3 Screw
10
Mounting Screws
11
Fixing Screws
for Latch SetX2
12
Fixing Screws
for Strike Plate X 2
www.waferlock.com
1
Outside Assembly with lever
13
Keys
14
Inner Lever Handle Set
15
Dismantling Lever/
Door Thickness Adjusting Tool
16
Battery (AAA)
Advertisement
Related Manuals for Waferlock L310
Summary of Contents for Waferlock L310
- Page 1 L310 Parts List www.waferlock.com Inside Assembly Outside Assembly with lever Inner Lever M3 Screws (Black) X 3 Keys M3 Screw Inner Lever Handle Set Backplate Rubber Gasket X1 Mounting Screws Dismantling Lever/ Door Thickness Adjusting Tool Strike Fixing Screws for Latch SetX2...
- Page 2 L310 Installation Manual www.waferlock.com retractor lock body view from inside of door 4 PIN 4 PIN 4 PIN 2 PIN 2 PIN 2 PIN 9V battery contact 1. Install latch. The bevel must face toward the 1. Attach the outside assembly to the door. Allow 1.
