Waferlock L342 Installation Manual

Inside control unit
2
3 Electronic mortise
4 Side plate
5
Lip Plate
6 Dust-prove box
7 Outside Lever
9
Thumb turn set with 2 screws
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment gen erates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:
. Reorient or relocate the receiving antenna.
. Increase the separation between the equipment and receiver.
. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
. Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate
this equipment. (Example - use only shielded interface cables when connecting to computer or peripheral devices).
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
L342 Parts List
8 inside Lever
10 Spring cage
Mounting plate
11
12 Inside rose
13 Spindle
14 Lever spring
15 Outer lever ring
16 Plate
17 Side plate screw
www.waferlock.com
Front Reader
1
18 Fix Screws for Lip Plate
& Mortise Lock
Lever screw
19
Mounting Screw (for control unit)
20
Mounting Screw (for plate)
21
22 Front reader slide cover screw
23 Stick screw
24 Screw (with stick screw)
25 ANSI cylinder with keys
Batteries (AAA)
version.01
