Summary of Contents for Diamond RF2G/Q
- Page 1 03/2022 Mod: RF2G/Q Production code: GST 12...
- Page 2 USER AND INSTALLATION MANUAL GAS STOVES (1 Burner-2 Burners-3 Burners) Références : RF1G/Q RF2G/Q RF3G/Q Fabrication française Made in France G03407 December 2020...
- Page 3 GAS STOVES Congratulations on the purchase of this upmarket cooking equipment made in France. You have chosen an appliance that combines the best technical qualities with great comfort of use. We wish you the greatest satisfaction. 1. SAFETY INSTRUCTIONS Please follow these instructions carefully to avoid the risk of fire, burns or other injuries and damage.
- Page 4 - Do not leave the hose or flexible tube (purchased separately in a shop) in contact with hot surfaces. - Do not bend or pinch the horse or flexible tube. - The appliance must not be used near combustible materials. - During use, make sure not to obstruct the air vents of the appliance.
-
Page 5: Conformity Of Use
3. CONFORMITY OF USE Use the device only to cook or keep warm some food. 4. OPERATING MODE These gas stoves are compact stainless steel appliances with 1, 2 or 3 burners depending on the model. The control of the cooking zones is independent, with a piezo ignition system and a safety thermocouple. - Page 6 Gas connection The appliances operate on the following gases : Butane G30, Propane G31, Natural Gas G20/G25. The appliances are supplied as standard with a butane/propane injector corresponding to category II2E+3+. The connection is made with a 1/2 thread. The heat output of the appliance is: - GST 7 / 145847 / PGAZ7 7 kW - GST 12 / 145853 / PGAZ12...
- Page 7 Article GC Installation of appliances to be used for catering Specific requirements for each type of establishment receiving the public. (hospitals, shops, etc…) Important: Never change the diameter of the injectors. Gas category table, according to the country of destination of the appliance.
- Page 8 Precautions of use Burner 5kw Maxi Mini Diameter of pans to be used 34cm 22cm Burner 7kw Maxi Mini Diameter of pans to be used 42cm 22cm Ignition 1. Push and turn the tap knob (n°1 in the photo) to the left to the large flame position.
-
Page 9: Cleaning And Maintenance
When you contact the service department of your Distributor or shop, give them the complete reference number of your appliance (commercial designation, type and serial number). This information can be found on the nameplate visible on the back of the appliance. 6. - Page 10 The following provisions are not exclusive of the benefit of the legal guarantee provided by articles 1641 and following of the Civil Code relating to defects and hidden defects. Exclusion clauses of the warranty Poor installation and maintenance, especially if they do not comply with the regulations in force or the instructions in this user manual.
