- Page 1 07/2016 Mod: INN/V5-A2 Production code: RD 800...
- Page 2 INSTRUCTIONS FOR INSTALLATION AND USE COOLING DISPLAY RD 800 F I / F B / F W Made in France JUILLET 2016 SG03355...
-
Page 3: Safety Instructions
COOLING DISPLAY RD 800 F I / F B / F W Congratulations for purchasing this top end professional equipment! You have chosen equipment that combines optimum technical properties with extreme user comfort. We want you to get the greatest possible satisfaction out of this equipment. 1. -
Page 4: Contents Of Cardboard Packaging
2. CONTENTS OF CARDBOARD PACKAGING Device : Cooling Display Accessories : 5 glass Technical documentation of the thermostat The present note 3. CONFORMITY OF USE Use the equipment exclusively for keeping food at temperatures included between 2°C and 10°C (except for meat). You get a refrigerating panoramic display RD80 which enables you to highlight your products (desserts, cakes, pies, cocktails, beverage, etc.). - Page 5 5. FUNCTIONING / MANIPULATION a) Installation / Assembly : - Place the equipment on a stable surface. - Position the accessories - A distance of 10 cm from the partition or the wall is considered enough. - Never place the device near a wall or near a partition made of combustible materials even if it is very well isolated.
- Page 6 Starting - Press on the on/off switch (n°3 on picture) to start the unit. The electronic thermostat turns on. - Wait for the unit to be at the right temperature (stop of the compressor). - Press on the light switch (n°1 on picture) to start the light. Temperature setting The electronic thermostat is preset in factory.
-
Page 7: Cleaning And Maintenance
6. CLEANING AND MAINTENANCE Disconnect the device - Clean regularly the metallic parts after each use by using only use non-abrasive products, warm water and wash liquid: avoid the abrasive toweling. Rinse your device with a wet sponge and dry it with a soft cloth. - Dry the device with a clean soft cloth. - Page 8 8. NORMS AND LEGALS DISPOSALS The device is conform to : 73/23 CEE: 19/02/1973 86/336 CEE: 03/05/1989 CEE: 92/31 CEE: 28/04/1992 CEE: 22/07/1993 EN 60335-1 EN 55104 EN 60555-2 EN 60555-3 In order to comply with the directive 2004/108/CE concerning the electromagnetic compatibility, and according to the norm EN 61000-3-11, the maximal impedance of the network accepted (Zmax) at the plug in point has to be under 0,42 Ω.The technician has to check this value, with the distributor if necessary.
- Page 9 10. GUARANTEE Conditions of guarantee The guarantee applicable to any device is the commercial guarantee of the distributor or the retailer. Please contact the store where you bought your device to know the precise conditions. The guarantee grants no right for damages. The dispositions which follow are not exclusive of the profit of the legal guarantee planned by articles 1641 and following ones of the Civil code relative to the defects and the latent defects.
- Page 10 Notice DEBALLAGE VITRINE REFRIGEREE / COOLING DISPLAY UNPACKING Couper les 2 sangles (1), puis retirer les 2 planches (2) et les 8 cornières (3). Cut the two straps (1), remove the 2 boards (2) and the 8 angles (3). Incliner légèrement la vitrine et glisser les planches (2) sous les roues avant. Fixer les planches (2) sur la palette avec les 8 vis fournies.
- Page 11 Notice DEBALLAGE VITRINE REFRIGEREE / COOLING DISPLAY UNPACKING Pousser la vitrine doucement sur les planches, retenir la vitrine dès que les planches s'inclinent. Slowly push the unit on the boards, and retain it as soon as the boards tilt. Respecter la notice, située à l'interieur de la vitrine pour l'utilisation. Respect the utilisation notice located inside the cooling display for use.
