- Page 1 DeviceEdge_AGX ORIN Series AIE-KX11/KX21/ KX12/KX22 USER MANUAL...
- Page 2 Document Change History Version Date Description Authors V1.0 2023/02/04 Initial Release. Joann Tung AIE-KX11/AIE-KX21/AIE-KX12/AIE-KX22 User Manual...
- Page 3 Aetina be liable to any person for any direct, indirect, special or other consequential damages arising from the use of any information contained herein, even if nvidia is expressly advised of the possibility of such damages.
- Page 4 All other product names or trademarks are properties of their respective owners. No ownership is implied or assumed for products, names or trademarks not herein listed by the publisher of this document. For more information about this and other Aetina products, please visit our web-site at: http://www.Aetina.com/...
- Page 5 Because of Aetina’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Aetina product is defective, it will be repaired or replaced at no charge during the warranty period. For out of warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references: 1. All cautions and warnings on the equipment should be noted. 2. Make sure the power source matches the power rating of the device. 3.
-
Page 7: Table Of Contents
4.1 Prepare the Materials ..................... 19 4.2 Hardware Connection ..................... 19 4.3 Setup Details ......................19 5. EdgeEye ..................20 5.1 Aetina 360 Edge Administration Platform ............... 20 5.2 Feature ........................21 5.3 System Requirements .................... 21 5.4 Order Information ....................22... -
Page 8: Product Specification
1. Product Specification DeviceEdge AGX Orin series – AIE-KX11/AIE-KX21/AIE-KX12/AIE-KX22 is a standard system, supporting for NVIDIA® Jetson AGX Orin. The system is with smart button for one-key recovery function to address critical system failure and real-time monitoring for status of device through the AIM (Aetina Intelligent Management). -
Page 9: Configuration
1.2 Configuration Table 1.1 Lists the SKU configuration currently available for the AIE-KX11/AIE-KX21/AIE-KX12/AIE- KX22. System configuration Specification AIE-KX11/AIE-KX12 AIE-KX21/AIE-KX22 Module Compatibility NVIDIA Jetson AGX ORIN 32GB NVIDIA Jetson AGX ORIN 64GB Storage 64GB eMMC 5.1 Display 1 x HDMI Type A Audio Line-out/Line-in/Mic (opt. - Page 10 Operating Temperature: -25°C ~ +70°C Temperature Storage Temperature: -40°C ~ +85°C Humidity 5 to 90% @ 40°C Related Humidity, Non-condensing AIE-KX11/AIE-KX21/AIE-KX12/AIE-KX22 User Manual...
-
Page 11: Hardware Information
2. Hardware Information 2.1 I/O Interface Figure 2.1 I/O Interface 2.2 External Connector Summary Location External Connector Description Front Power Power pushbutton DC IN Power Connector 9V-39V 10G LAN 1G LAN HDMI RJ-45 Gigabit Ethernet connector (PoE PD function) USB3.2 Gen1 Type-A connector USB 3.2 Type-C Gen 2 USB 2.0 Type-C (OTG only) Rear... -
Page 12: External I/O Interface
2.2.1 External I/O Interface Power Item Detail Location Front Type Pushbutton Power input connector Item Detail Location Front Type 9V to 36V 4-pin DC Jack 10G LAN / 1G LAN Item Detail Location Front Type RJ-45 Connector ... - Page 13 DB15 female connector Item Detail Location Rear Type I2C/USB/SPI Pin NO. Description SPI_MOSI SPI_SCK SPI_MISO SPI_CS1 SPI_CS0 I2C_1_CLK I2C_1_DAT I2C_2_CLK I2C_2_DAT 3.3V USB_DM USB_DP DB15 female connector Item Detail Location Rear Type GPIO/UART Pin NO. Description GPIO1 GPIO2 GPIO3 GPIO4 AIE-KX11/AIE-KX21/AIE-KX12/AIE-KX22 User Manual...
- Page 14 GPIO5 UART1_TX UART1_RX UATR1_CTS UATR1_RTS 3.3V UATR4_RT UATR4_TX GPIO connector: DB9 male connector Item Detail Location Rear Type RS-422/RS-485 Pin NO. Description TxD+ TxD- RxD-/Data- RxD+/Data+ GPIO connector: DB9 male connector Item Detail Location Rear AIE-KX11/AIE-KX21/AIE-KX12/AIE-KX22 User Manual...
- Page 15 Type RS-232 Pin NO. Description GPIO connector: DB9 male connector Item Detail Location Rear Type CAN 1 Pin NO. Description CAL_L CAL_H GPIO connector: DB9 male connector Item Detail Location Rear AIE-KX11/AIE-KX21/AIE-KX12/AIE-KX22 User Manual...
- Page 16 Type CAN 2 Pin NO. Description CAL_L CAL_H AI button (One-key recovery pushbutton) Item Detail Location Side Type Pushbutton Reset & Recovery button Item Detail Location Side Type Pushbutton SIM & SD Card slot Item Detail Location Rear Type Performed socket...
-
Page 17: Power Consumption
2.3 Power Consumption The power consumption shown as below is the theoretical value with AGX Orin module installed on AIE-KX11/AIE-KX21/AIE-KX12/AIE-KX22. Specification Theoretical Maximum System power Idle TBD (Connect with keyboard, mouse, and HDMI display) TBD (Connect with keyboard, mouse and HDMI display with CPU and GPU Full loading 100% loading) Please refer to the following power consumption of individual I/O interface according to your use... - Page 18 AIE-KX11/AIE-KX21/AIE-KX12/AIE-KX22 User Manual...
-
Page 19: Software Installation
3. Software Installation Aetina NVIDIA Jetson products have built-in BSP so the users don’t have to install it after getting the products. Since we develop our own BSP, the users may need to follow the BSP installation SOP to re-install/upgrade/downgrade the BSP. Please download the BSP installation SOP at below link. -
Page 20: Initial Setup
4. Initial Setup Before using AIE-KX11/AIE-KX21/AIE-KX12/AIE-KX22, please follow the steps below to have initial setup. 4.1 Prepare the Materials Please prepare the materials list below. A monitor with HDMI and respective cables USB keyboard and mouse Ethernet cable 4.2 Hardware Connection Here is the AIE-KX11/AIE-KX21/AIE-KX12/AIE-KX22... -
Page 21: Edgeeye
5.1 Aetina 360 Edge Administration Platform Introduction EdgeEye, the Aetina 360 Edge Administration Platform, is a browser-accessed management platform that allows you to monitor and manage edge IOT device around the world. EdgeEye can monitor device’s hardware components’ utilization and capacity and send notifications immediately. EdgeEye accomplishes this by gathering data from all connected devices and storing it on a central server, either in the cloud or on one’s intranet. -
Page 22: Feature
IntelR Core™ i3 2.3 Ghz CPU or above I 4 GB RAM I 20 GB root partition for the system I 100 GB data storage Operating System: Ubuntu 14.04+ I Docker 17.03+ Client Support all Aetina products AIE-KX11/AIE-KX21/AIE-KX12/AIE-KX22 User Manual... -
Page 23: Order Information
5.4 Order Information Model name Description AIE-KX11-1-A1 AIE-KX11 w/ AGX ORIN 32G, 1 x HDMI, 2 x USB-A, 1 x USB-MICRO AB, 1 x RJ-45 GbE PORT, 1 x RJ-45 10GbE PORT, 2 x RJ-45 IEEE802.3af GbE PSE PORT, 2 x FAN, 9 to 36V DC INPUT, -25°C to +70°C AIE-KX21-1-A1 AIE-KX21 w/ AGX ORIN 64G, 1 x HDMI, 2 x USB-A, 1 x USB-MICRO AB, 1 x RJ-45 GbE PORT, 1 x RJ-45 10GbE PORT, 2 x RJ-45 IEEE802.3af GbE... - Page 24 Aetina Corporation | Headquarters 2F-1, No.237, Sec.1, Datong Rd., Xizhi Dist., New Taipei City 221, TAIWAN Phone: +886-2-7709 2568 Fax : +886-2-7746 1102 Mail : sales@Aetina.com www.Aetina.com Copyright © 2022 Aetina Corporation. All rights reserved.
