- Page 1 DeviceEdge_Orin Nano/NX Series AIE-KO22/KO32 AIE-KN32/KN42 USER MANUAL...
- Page 2 Document Change History Version Date Description V1.0 2023/07/18 Initial Release. AIE-KO22/AIE-KO32/AIE-KN32/AIE-KN42 User Manual...
- Page 3 Aetina be liable to any person for any direct, indirect, special or other consequential damages arising from the use of any information contained herein, even if nvidia is expressly advised of the possibility of such damages.
- Page 4 All other product names or trademarks are properties of their respective owners. No ownership is implied or assumed for products, names or trademarks not herein listed by the publisher of this document. For more information about this and other Aetina products, please visit our web-site at: http://www.Aetina.com/...
- Page 5 Because of Aetina’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Aetina product is defective, it will be repaired or replaced at no charge during the warranty period. For out of warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references: 1. All cautions and warnings on the equipment should be noted. 2. Make sure the power source matches the power rating of the device. 3.
-
Page 7: Table Of Contents
5.1 Prepare the Materials ................... 17 5.2 Hardware Connection ..................17 5.3 Setup Details ......................17 6. EdgeEye ..................18 6.1 Aetina 360 Edge Administration Platform ............18 6.2 Feature ........................19 6.3 System Requirements ..................19 AIE-KO22/AIE-KO32/AIE-KN32/AIE-KN42 User Manual... -
Page 8: Product Specification
1. Product Specification DeviceEdge Orin NX/Orin Nano series – AIE-KO22/AIE-KO32/AIE-KN32/AIE-KN42 is a standard system, supporting for NVIDIA® Jetson Orin NX/Orin Nano. 1.1 Features Supports NVIDIA Jetson Orin Nano/NX Series ⚫ 1 x M.2 B-Key/E-Key/M-Key (128GB built-in) ⚫ 2 x RJ-45 GbE Ports ⚫... -
Page 9: Configuration
1.2 Configuration Table 1.1 Lists the SKU configuration currently available for the AIE-KO22/AIE-KO32/AIE-KN32/AIE- KN42. ◼ System configuration Specification AIE-KO21 / AIE-KO31 AIE-KN32 / AIE-KN42 ◼ Module Compatibility NVIDIA Jetson Orin Nano 4/8G NVIDIA Jetson Orin NX 8/16GB AI Performance 20 TOPS 40 TOPS 70 TOPS 100 TOPS... - Page 10 Idle: 9.6 W Idle: 10.5 W Full Loading: 30.05* W Full Loading: 39.55* W Idle configuration: Connect with Keyboard, Mouse and HDMI Display Power Consumption Full Loading configuration: Connect with keyboard, mouse, HDMI display and LAN with CPU and GPU 100% loading; including system fan*1 and module fan*1 Dimension (W x D x H) 196.5 x 124 x 68 mm (7.73 x 4.88 x 2.67 in)
-
Page 11: Hardware Information
2. Hardware Information 2.1 I/O Interface Figure 2.1 AIE-KO22/AIE-KO32/AIE-KN32/AIE-KN42 I/O Interface 2.2 External Connector Summary Location External Connector Description Front Power Power pushbutton DC IN Power Connector 12V-24V 1G LAN x 2 HDMI HDMI 2.0 Type-A USB 3.2 Type-A Gen 2 USB 2.0 Type-C (OTG only) Rear GPIO/UART/I2C... -
Page 12: External I/O Interface
2.2.1 External I/O Interface ◼ Power Item Detail Location Front Type Pushbutton ◼ Power input connector Item Detail Location Front Type 12V to 24V 4-Pin DC Jack ◼ 1G LAN Item Detail Location Front Type RJ-45 Connector ◼ HDMI Item Detail Location Front... - Page 13 ◼ GPIO / UART / I2C Item Detail Location Rear Type DB15 female connector Pin # Definition Notes Pin # Definition Notes GPIO_1 (GPIO17 / IN/OUT GPIO_2 (GPIO11 / IN/OUT PP.04 444) PAC.05 491) GPIO_3 (PWM01 / IN/OUT GPIO_4 (GPIO27 / IN/OUT PR.00 456) PN.01 433)
- Page 14 Pin # Definition Pin # Definition TxD+ TxD- RxD-/Data- RxD+/Data+ ◼ CAN Item Detail Location Rear Type DB9 male connector Pin # Definition Pin # Definition CAL_L CAL_H ◼ Reset & Recovery Button Item Detail Location Side Type Pushbutton ◼ SIM Card slot Item Detail Location...
-
Page 15: Power Consumption
2.3 Power Consumption The power consumption shown as below is the theoretical value with AGX Orin module installed on AIE-KO22/AIE-KO32/AIE-KN32/AIE-KN42. AIE-KO22/AIE-KO32 Specification Theoretical Maximum System power Idle 5.5W (Connect with keyboard, mouse, and HDMI display) 30.05W (Connect with keyboard, mouse, HDMI display and LAN with CPU and Full loading GPU 100% loading;... -
Page 16: Mechanical Dimensions
2.4 Mechanical Dimensions ◼ System & Mounting Dimensions AIE-KO22/AIE-KO32/AIE-KN32/AIE-KN42 User Manual... -
Page 17: Software Installation
3. Software Installation Aetina NVIDIA Jetson products have built-in BSP so the users don’t have to install it after getting the products. Since we develop our own BSP, the users may need to follow the BSP installation SOP to re-install/upgrade/downgrade the BSP. Please visit the Aetina website or contact with Aetina FAE at Tech_support@aetina.com... -
Page 18: Initial Setup
5. Initial Setup Before using AIE-KO22/AIE-KO32/AIE-KN32/AIE-KN42, please follow the steps below to have initial setup. 5.1 Prepare the Materials Please prepare the materials list below. ◼ A monitor with HDMI and respective cables ◼ USB keyboard and mouse ◼ Ethernet cable 5.2 Hardware Connection Here is the AIE-KO22/AIE-KO32/AIE-KN32/AIE-KN42 below and for the initial setup, users will need to connect LAN port, keyboard and mouse via USB interface, HDMI interface, and power connector. -
Page 19: Edgeeye
Introduction To help clients efficiently and systematically manage edge devices deployed in different locations, Aetina offers several cloud management platforms. For example, EdgeEye, an Aetina browser- accessed management platform, allows clients to conveniently manage edge devices via intranet- connected cell phones, tablets, or laptops, no matter where the devices are deployed. It shows... -
Page 20: Feature
Safari:5.1+ Server Hardware Minimum Requirements: Intel® Core™ i5 2.3 Ghz CPU or above 32 GB RAM 200 GB root partition for the system Operating System: Linux Ubuntu 20.04+ Browser: Google Chrome 9.0+ Client Support all Aetina products AIE-KO22/AIE-KO32/AIE-KN32/AIE-KN42 User Manual... - Page 21 Aetina Corporation | Headquarters 2F-1, No.237, Sec.1, Datong Rd., Xizhi Dist., New Taipei City 221, TAIWAN Phone: +886-2-7709 2568 Fax : +886-2-7746 1102 Mail : sales@Aetina.com www.Aetina.com Copyright © 2022 Aetina Corporation. All rights reserved.
