- Page 1 DeviceEdge_Orin Nano/NX Series AIE-PO22/PO32 AIE-PN32/PN42 USER MANUAL...
- Page 2 Document Change History Version Date Description V1.0 2023/08/01 Initial Release. AIE-PO22/AIE-PO32/AIE-PN32/AIE-PN42 User Manual...
- Page 3 Aetina be liable to any person for any direct, indirect, special or other consequential damages arising from the use of any information contained herein, even if nvidia is expressly advised of the possibility of such damages.
- Page 4 All other product names or trademarks are properties of their respective owners. No ownership is implied or assumed for products, names or trademarks not herein listed by the publisher of this document. For more information about this and other Aetina products, please visit our web-site at: http://www.Aetina.com/...
- Page 5 Because of Aetina’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Aetina product is defective, it will be repaired or replaced at no charge during the warranty period. For out of warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 6 Exposure to moisture – Device is not working as expected or in a manner as described in this manual – The device is dropped or damaged – vi. Any obvious signs of damage displayed on the device – AIE-PO22/AIE-PO32/AIE-PN32/AIE-PN42 User Manual...
-
Page 7: Table Of Contents
5. Initial Setup ................18 5.1 Prepare the Materials ................... 18 5.2 Hardware Connection ..................18 5.3 Setup Details ......................18 6. EdgeEye ..................19 6.1 Aetina Edge Administration Platform ..............19 6.2 Feature ........................20 6.3 System Requirements ..................20 AIE-PO22/AIE-PO32/AIE-PN32/AIE-PN42 User Manual... -
Page 8: Product Specification
1. Product Specification DeviceEdge Orin NX/Orin Nano series – AIE-PO22/AIE-PO32/AIE-PN32/AIE-PN42 is a standard system, supporting for NVIDIA® Jetson Orin NX/Orin Nano. 1.1 Features Supports NVIDIA Jetson Orin Nano/NX Series ⚫ 1 x M.2 B-Key/E-Key/M-Key (128GB built-in) ⚫ 2 x RJ-45 GbE Ports ⚫... -
Page 9: Configuration
1.2 Configuration ◼ System configuration Specification AIE-PO22 / AIE-PO32 AIE-PN32 / AIE-PN42 Module Compatibility NVIDIA Jetson Orin Nano 4/8G NVIDIA Jetson Orin NX 8/16GB AI Performance 20/40 TOPS 70/100 TOPS 512 Core NVIDIA 1024 Core NVIDIA 1024 Core NVIDIA Ampere, with... - Page 10 10 G, IEC 60068-2-27, half sine, 11 ms duration Operating Temp.: -25°C ~ +55°C (-13°F ~ +131°F) Temperature Storage Temp.: -40°C ~ +85°C (-40°F ~ +185°F) Humidity 95% @ 40°C (104°F) (non-condensing) Certification CE / FCC Class A / UKCA AIE-PO22/AIE-PO32/AIE-PN32/AIE-PN42 User Manual...
-
Page 11: Hardware Information
2. Hardware Information 2.1 I/O Interface Figure 2.1 AIE-PO22/AIE-PO32/AIE-PN32/AIE-PN42 I/O Interface 2.2 External Connector Summary Location External Connector Description Front Power Power pushbutton DC IN Power Connector 12V-24V 1G LAN x 2 HDMI HDMI 2.0 Type-A USB 3.2 Gen 2 Type-A x 2 USB 2.0 Type-C (OTG only) -
Page 12: External I/O Interface
Type Pushbutton ◼ Power input connector Item Detail Location Front Type 12V to 24V 4-Pin DC Jack ◼ 1G LAN Item Detail Location Front Type RJ-45 Connector ◼ HDMI Item Detail Location Front Type HDMI 2.0 Type-A AIE-PO22/AIE-PO32/AIE-PN32/AIE-PN42 User Manual... - Page 13 GPIO_1 (GPIO17 / IN/OUT GPIO_2 (GPIO11 / IN/OUT PP.04 444) PAC.05 491) GPIO_3 (PWM01 / IN/OUT GPIO_4 (GPIO27 IN/OUT PR.00 456) / PN.01 433) GPIO_5 (GPIO35 / IN/OUT I2C_CLK PH.00 391) I2C_SDA UART_TX UART_RX 3.3V UART_CTS UART_RTS AIE-PO22/AIE-PO32/AIE-PN32/AIE-PN42 User Manual...
- Page 14 ◼ RS 422 / RS 485 (2-in-1) Item Description Location Left Type DB9 male connector Notes Default setting is RS-485 mode (Data-/+) Pin # Definition Pin # Definition TxD+ TxD- RxD-/Data- RxD+/Data+ ◼ CAN Item Description Location Left DB9 male connector Type AIE-PO22/AIE-PO32/AIE-PN32/AIE-PN42 User Manual...
- Page 15 Pin # Definition Pin # Definition CAL_L CAL_H ◼ Reset & Recovery Button Item Detail Location Right Type Pushbutton ◼ SIM Card slot Item Detail Location Rear Type Performed socket AIE-PO22/AIE-PO32/AIE-PN32/AIE-PN42 User Manual...
-
Page 16: Power Consumption
Theoretical Maximum System power USB 3.2 Gen1 Type A (per Port) 4.5 W USB Type C 4.5 W HDMI 0.25 W M.2 E KEY M.2 M KEY M.2 B KEY CAN Bus SD Card 0.72 W RJ45(1G) 0.83 W AIE-PO22/AIE-PO32/AIE-PN32/AIE-PN42 User Manual... -
Page 17: Mechanical Dimensions
2.4 Mechanical Dimensions ◼ System & Mounting Dimensions AIE-PO22/AIE-PO32/AIE-PN32/AIE-PN42 User Manual... -
Page 18: Software Installation
3. Software Installation Aetina NVIDIA Jetson products have built-in BSP so the users don’t have to install it after getting the products. Since we develop our own BSP, the users may need to follow the BSP installation SOP to re-install/upgrade/downgrade the BSP. -
Page 19: Initial Setup
◼ USB keyboard and mouse ◼ Ethernet cable 5.2 Hardware Connection Here is the AIE-PO22/ AIE-PO32/ AIE-PN32/ AIE-PN42 below and for the initial setup, users will need to connect LAN port, keyboard and mouse via USB interface, HDMI interface, and power connector. -
Page 20: Edgeeye
Introduction To help clients efficiently and systematically manage edge devices deployed in different locations, Aetina offers several cloud management platforms. For example, EdgeEye, an Aetina browser- accessed management platform, allows clients to conveniently manage edge devices via intranet- connected cell phones, tablets, or laptops, no matter where the devices are deployed. It shows... -
Page 21: Feature
Safari:5.1+ Server Hardware Minimum Requirements: Intel® Core™ i5 2.3 Ghz CPU or above 32 GB RAM 200 GB root partition for the system Operating System: Linux Ubuntu 20.04+ Browser: Google Chrome 9.0+ Client Support all Aetina products AIE-PO22/AIE-PO32/AIE-PN32/AIE-PN42 User Manual... - Page 22 Aetina Corporation | Headquarters 2F-1, No.237, Sec.1, Datong Rd., Xizhi Dist., New Taipei City 221, TAIWAN Phone: +886-2-7709 2568 Fax : +886-2-7746 1102 Mail : sales@Aetina.com www.Aetina.com Copyright © 2022 Aetina Corporation. All rights reserved.
