- Page 1 MegaEdge Series AIP-SQ67-A1 USER MANUAL...
- Page 2 Document Change History Version Date Description Authors V1.0 2022/12/12 Initial Release. Ginnie Lin V1.1 2023/05/29 PIN define Update Ginnie Lin AIP-SQ67 Series User Manual...
- Page 3 Aetina be liable to any person for any direct, indirect, special or other consequential damages arising from the use of any information contained herein, even if nvidia is expressly advised of the possibility of such damages.
- Page 4 All other product names or trademarks are properties of their respective owners. No ownership is implied or assumed for products, names or trademarks not herein listed by the publisher of this document. For more information about this and other Aetina products, please visit our web-site at: http://www.Aetina.com/...
- Page 5 Because of Aetina’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Aetina product is defective, it will be repaired or replaced at no charge during the warranty period. For out of warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references: 1. All cautions and warnings on the equipment should be noted. 2. Make sure the power source matches the power rating of the device. 3.
- Page 7 Box Contents Item Quantity MegaEdge System Terminal Plug SATA Tray Screws Bracket, mounting AIP-SQ67 Series User Manual...
-
Page 8: Table Of Contents
Contents 1.Product Specification……………………………………… 7 1.1 Features……………………………………………………………………. 8 1.2 Specifications.……………………………………………………………..9 2.Hardware Information……………………………………. 10 2.1 I/O Interface……………………………………………………………… 10 2.2 Component Installation……………….....………………….12 2.3 System setup…………………......………………………..16 2.4 Removing Power……………………...........16 2.5 System Dimensions……………………......………………..17 3.BIOS Setup…………………………………………………. 18 3.1 Beep Codes……………………......………………………….18 3.2 Entering BIOS Setup……………………......……………….19 3.3 BIOS Controls……………………......……………………….19 3.4 BIOS Main Tab……………………......……………………..20 3.5 BIOS Advanced Tab……………………......………………..21 3.6 BIOS Chipset Tab……………………......…………………..26... -
Page 9: Product Specification
1. Product Specifications 1.1 Features With the advantages of high computing performance, High stability, and high flexibility EdgeEye, the Aetina Administration platform for device monitor Rich I/O interface design for AI Image Input application Two swappable 2.5" hard drive bays ... -
Page 10: Specifications
1.2 Specifications System Specifications Specification AIP-SQ67-A1 Processor Supports Intel® 12th Gen Core™ i7/i5 processors, TDP under 65W Chipset Intel® Q670E Chipset Supports 2x DDR5 4800MHz SO-DIMM, Max. Capacity 32 GB/Per DIMM, Memory Total 64 GB MXM Type A、Type B、Type B+ (Supports MXM PCIe Gen4 x16) GPU(Optional) 2x 2.5"... -
Page 11: Hardware Information
2. Hardware Information 2.1 I/O Interface AIP-SQ67 Series User Manual... - Page 12 I/O Connectors Location I/O Connector Description Power On/Off Power Push-button USB ports 6x USB3.2 Gen2 Type-A connector(10G) 1x USB-C (20G) 5x RJ45 LAN connector Act/Link LED, Speed LED 10-Off / Front 100-Green / 1000-Yellow(2.5G) Digital IO 1x 7-bits GPIO COM Ports 4x COM(RS232/RS485/RS422) SATA III SSD...
-
Page 13: Component Installation
2.2 Component Installation Accessing the System The system features a lockable top cover. Open the cover to access the motherboard. Remove the system cover to access other system components. The system can be accessed without powering down the system. 1. - Page 14 CPU Cooler Installation 1. Remove the top cover as above. 2. Assemble 4 screws (on the CPU Cooler) to fix the cooler on the SQ67 system. AIP-SQ67 Series User Manual...
- Page 15 Memory Installation Slowly insert the DRAM modules into the slots, ensuring that the clips on both sides of the slot securely click into place. When removing the modules, the clips on either side of the module must first be un-clipped. AIP-SQ67 Series User Manual...
- Page 16 Storage Installation (2.5” HDD/SSD) 1. Loosen 2 thumb screws on hard drive bay, then pull out. 2. Install HDD/SSD with 4 screws on the HDD/SSD tray. 3. Push back the hard drive bay into the system and secure with thumb screws. AIP-SQ67 Series User Manual...
-
Page 17: System Setup
2.3 Setup 1. Before you start Thank you for choosing our product. Before you start using the system, please make sure you follow the instructions below. Use DP1/2/3/4 connector setting when you already installed MXM card. Use DP5 connector setting without MXM card in the system. ... -
Page 18: System Dimensions
2.5 System Dimensions AIP-SQ67 Series User Manual... -
Page 19: Bios Setup
3. BIOS Setup 3.1 Beep Codes PEI Beep Codes Description Memory not Installed Install Per Memory routine in PEI Core was called twice Recovery started DXEIPL was not found DXE Core firmware volume was not found Recovery failed S3 resume failed Reset PPI is not available DXE Beep Codes Description... -
Page 20: Entering Bios Setup
3.2 Entering BIOS Setup To enter the BIOS setup, press the DELETE key during system boot. 3.3 BIOS Controls The BIOS is entirely controlled by the keyboard, using the following keys: Hot Key Description Left/right Switch selected menu Up/down Select item Enter Confirm selection or open sub menu Plus/minus or F5/F6... -
Page 21: Bios Main Tab
3.4 BIOS Main Tab Location: Main Setting Name Available Options System Date 01/01/1998 – 31/12/9999 (DD/MM/YYYY) System Time 00:00:00 – 23:59:59 (HH/MM/SS) AIP-SQ67 Series User Manual... -
Page 22: Bios Advanced Tab
3.5 BIOS Advanced Tab Location: Advanced > ACPI Settings Setting Name Available Options Wake System from S5 via RTC Enabled, Disabled Wake up hour 0 – 23 Wake up minute 0 – 59 Wake up second 0 – 59 State After G3 S0 State, S5 State, Last State Wake on PME... - Page 23 Location: Advanced > Power & Performance > CPU – Power Management Control Setting Name Available Options Intel® SpeedStep™ Enabled, Disabled Turbo Mode Enabled, Disabled C states Enabled, Disabled Package C State Limit C0/C1, C2, C3, C6, C7, C7S, C8, C9, C10, CPU Default, Auto Location: Advanced >...
- Page 24 Location: Advanced > DIO Settings Setting Name Available Options DIO PIN Type 1 Output Low, Output High, Input DIO PIN Type 2 Output Low, Output High, Input DIO PIN Type 3 Output Low, Output High, Input DIO PIN Type 4 Output Low, Output High, Input DIO PIN Type 5 Output Low, Output High, Input...
- Page 25 FD/RPM 2 0 – 100 FD/RPM 3 0 – 100 FD/RPM 4 0 – 100 SYSFAN 2 Mode Manual mode, SMART FAN Temperature 1 0 – 100 Temperature 2 0 – 100 Temperature 3 0 – 100 Temperature 4 0 – 100 FD/RPM 1 0 –...
- Page 26 Location: Advanced > USB Configuration Setting Name Available Options USB Mass Storage Driver Support Enabled, Disabled Location: Advanced > Network Stack Configuration Setting Name Available Options Network Stack Enabled, Disabled AIP-SQ67 Series User Manual...
-
Page 27: Bios Chipset Tab
3.6 BIOS Chipset Tab Location: Chipset > System Agent (SA) Configuration Setting Name Available Options VT-d Enabled, Disabled Location: Chipset > System Agent (SA) Configuration > Graphics Configuration Setting Name Available Options Primary Display Auto, IGFX, PEG Slot, PCH PCI Internal Graphics Auto, Disabled, Enabled Location: Chipset >... - Page 28 Location: Chipset > System Agent (SA) Configuration > PCIe Configuration > PCI Express Root Port 2 Setting Name Available Options PCI Express Root Port 2 Enabled, Disabled PCIe Speed Auto, Gen1, Gen2, Gen3, Gen4, Gen5 Location: Chipset > System Agent (SA) Configuration > PCIe Configuration > PCI ...
- Page 29 Location: Chipset > PCH-IO Configuration > PCI Express Configuration > M2M2 Setting Name Available Options M2M2 Enabled, Disabled PCIe Speed Auto, Gen1, Gen2, Gen3, Gen4 Location: Chipset > PCH-IO Configuration > SATA Configuration Setting Name Available Options SATA Controller(s) Enabled, Disabled SATA Mode Selection AHCI...
-
Page 30: Bios Security Tab
3.7 BIOS Security Tab Location: Security Setting Name Available Options Administrator Password 3 to 20 characters User Password 3 to 20 characters Location: Security > Secure Boot Setting Name Available Options Secure Boot Enabled, Disabled Secure Boot Mode Standard, Custom Restore Factory Keys Yes, No... -
Page 31: Bios Boot Tab
3.8 BIOS Boot Tab Location: Boot Setting Name Available Options Setup Prompt Timeout 0 - 9999 Bootup Num Lock State On, Off Quiet Boot Enabled, Disabled OS Selection Windows, Linux, Real Time OS Boot Option #1 UEFI: Built-in EFI Shell, Disabled AIP-SQ67 Series User Manual... -
Page 32: Edgeeye
Aetina 360 Edge Administration Platform Introduction EdgeEye, the Aetina 360 Edge Administration Platform, is a browser-accessed management platform that allows you to monitor and manage edge IOT device around the world. EdgeEye can monitor device’s hardware components’ utilization and capacity and send notifications immediately. EdgeEye accomplishes this by gathering data from all connected devices and storing it on a central server, either in the cloud or on one’s intranet. - Page 33 IntelR Core™ i3 2.3 Ghz CPU or above I 4 GB RAM I 20 GB root partition for the system I 100 GB data storage Operating System: Ubuntu 14.04+ I Docker 17.03+ Client Support all Aetina products. AIP-SQ67 Series User Manual...
- Page 34 Aetina Corporation | Headquarters 2F-1, No.237, Sec.1, Datong Rd., Xizhi Dist., New Taipei City 221, TAIWAN Phone: +886-2-7709 2568 Fax : +886-2-7746 1102 Mail : sales@Aetina.com www.aetina.com Copyright © 2023 Aetina Corporation. All rights reserved.
