  • Page 1 DeviceEdge_AGX Orin Series AIE-PX11/AIE-PX12 AIE-PX21/AIE-PX22 USER MANUAL...
  • Page 2 Document Change History Version Date Description V1.0 2023/08/01 Initial Release. V1.1 2023/10/30 Update DS information AIE-PX11/AIE-PX12/AIE-PX21/AIE-PX22 User Manual...
  • Page 3 Aetina be liable to any person for any direct, indirect, special or other consequential damages arising from the use of any information contained herein, even if nvidia is expressly advised of the possibility of such damages.
  • Page 4 All other product names or trademarks are properties of their respective owners. No ownership is implied or assumed for products, names or trademarks not herein listed by the publisher of this document. For more information about this and other Aetina products, please visit our web-site at: http://www.Aetina.com/...
  • Page 5 Because of Aetina’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Aetina product is defective, it will be repaired or replaced at no charge during the warranty period. For out of warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
  • Page 6 Exposure to moisture – Device is not working as expected or in a manner as described in this manual – The device is dropped or damaged – vi. Any obvious signs of damage displayed on the device – AIE-PX11/AIE-PX12/AIE-PX21/AIE-PX22 User Manual...
  • Page 7: Table Of Contents

    4. Recovery Mode ................ 18 5. Initial Setup ................19 Prepare the Materials ..................19 Hardware Connection ..................19 Setup Details......................19 6. EdgeEye ................... 20 Aetina Edge Administration Platform .............. 20 Feature ......................... 21 System Requirements ..................21 AIE-PX11/AIE-PX12/AIE-PX21/AIE-PX22 User Manual...
  • Page 8: Introduction

    1. Introduction DeviceEdge AGX Orin series – AIE-PX11/ AIE-PX12/ AIE-PX21/ AIE-PX22 is a standard system, supporting for NVIDIA Jetson AGX Orin. 1.1 Features Supports NVIDIA Jetson AGX Orin™ 32GB/64GB module ⚫ 2/4 x IEEE 802.3af GbE PSE ports ⚫ 1 x GbE/1 x 10GbE LAN port ⚫...
  • Page 9: Specifications

    1 x M.2 M-Key 2280 (supports NVMe; PCIe x2 Gen3) 1 x microSD Card Slot MISC. Function 1 x Power / Recovery / Reset Button Power Input/Connector DC-IN 9 to 36 VDC / 4-Pin DC Jack Power Connector Power Consumption Idle: 7.5 W Idle: 8 W AIE-PX11/AIE-PX12/AIE-PX21/AIE-PX22 User Manual...
  • Page 10 Operating Temperature: -25°C ~ +55°C (-13°F ~ +131°F) ) with 0.5 m/s air Temperature flow Storage Temperature: -40°C ~ +85°C (-40°F ~ +185°F) Humidity 95% @ 40°C (104°F) (non-condensing) Certification CE / FCC Class A / UKCA AIE-PX11/AIE-PX12/AIE-PX21/AIE-PX22 User Manual...
  • Page 11: Hardware Information

    2. Hardware Information 2.1 I/O Interface Figure 2.1 AIE-PX11/AIE-PX12/AIE-PX21/AIE-PX22 I/O Interface 2.2 External Connector Summary Location External Connector Description Front Power Power pushbutton DC IN Power Connector 9V-36V 10G LAN 10 GbE Port 1G LAN 1 GbE Port PoE Ports IEEE 802.3af GbE PSE ports x 4...
  • Page 12: Connector Interface

    IEEE 802.3af compliant, Power Output 15W per Port ◼ HDMI Item Description Location Front Type HDMI Type-A female connector ◼ Dual USB3.2 Gen1 Type-A connector Item Description Location Front Type Type-A USB connector Refer to USB Standard AIE-PX11/AIE-PX12/AIE-PX21/AIE-PX22 User Manual...
  • Page 13 Description Location Rear Type DB15 female connector Pin # Definition Pin # Definition SPI_MOSI SPI_SCK SPI_MISO SPI_CS1 SPI_CS0 I2C_1_CLK I2C_1_DAT I2C_2_CLK I2C_2_DAT 3.3V USB_DM USB_DP ◼ GPIO / UART Item Description Location Rear Type DB15 female connector AIE-PX11/AIE-PX12/AIE-PX21/AIE-PX22 User Manual...
  • Page 14 ◼ RS 422 / RS 485 (2-in-1) Item Description Location Rear Type RS-422/RS-485 (2-in-1) Notes Default setting is RS-485 mode (Data-/+) Pin # Definition Pin # Definition TxD+ TxD- RxD-/Data- RxD+/Data+ ◼ RS 232 Item Description Location Rear Type RS-232 AIE-PX11/AIE-PX12/AIE-PX21/AIE-PX22 User Manual...
  • Page 15 Definition ◼ CAN1 Item Description Location Rear Type DB9 male connector Pin # Definition Pin # Definition CAL_L CAL_H ◼ CAN2 Item Description Location Rear Type DB9 male connector Pin # Definition Pin # Definition CAL_L CAL_H AIE-PX11/AIE-PX12/AIE-PX21/AIE-PX22 User Manual...
  • Page 16 ◼ Reset & Recovery Button Item Description Location Rear Type Pushbutton AIE-PX11/AIE-PX12/AIE-PX21/AIE-PX22 User Manual...
  • Page 17: Power Consumption

    USB Type C 4.5 W HDMI 0.25 W M.2 E KEY M.2 M KEY M.2 B KEY CAN Bus SD Card 0.72 W RJ45(1G) 0.83 W RJ45(10G) 3.43 W PoE (per Port) 15 W (IEEE 802.3af compliant) AIE-PX11/AIE-PX12/AIE-PX21/AIE-PX22 User Manual...
  • Page 18: Mechanical Dimensions

    2.4 Mechanical Dimensions ◼ System & Mounting Dimensions Integration assembly drawing for AIE-PX11/ AIE-PX12/ AIE-PX21/ AIE-PX22 system. AIE-PX11/AIE-PX12/AIE-PX21/AIE-PX22 User Manual...
  • Page 19: Software Installation

    3. Software Installation Aetina NVIDIA Jetson products have built-in BSP so the users don’t have to install it after getting the products. Since we develop our own BSP, the users may need to follow the BSP installation SOP to re-install/upgrade/downgrade the BSP.
  • Page 20: Initial Setup

    ◼ USB keyboard and mouse ◼ Ethernet cable 5.2 Hardware Connection Here is the AIE-PX11/ AIE-PX12/ AIE-PX21/ AIE-PX22 below and for the initial setup, users will need to connect LAN port, keyboard and mouse via USB interface, HDMI interface, and power connector.
  • Page 21: Edgeeye

    Introduction To help clients efficiently and systematically manage edge devices deployed in different locations, Aetina offers several cloud management platforms. For example, EdgeEye, an Aetina browser- accessed management platform, allows clients to conveniently manage edge devices via intranet- connected cell phones, tablets, or laptops, no matter where the devices are deployed. It shows...
  • Page 22: Feature

    Safari:5.1+ Server Hardware Minimum Requirements: Intel® Core™ i5 2.3 Ghz CPU or above 32 GB RAM 200 GB root partition for the system Operating System: Linux Ubuntu 20.04+ Browser: Google Chrome 9.0+ Client Support all Aetina products AIE-PX11/AIE-PX12/AIE-PX21/AIE-PX22 User Manual...
