DeviceEdge_AGX Orin Series
AIE-PX13/AIE-PX23
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIE-PX13 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Aetina AIE-PX13

  • Page 1 DeviceEdge_AGX Orin Series AIE-PX13/AIE-PX23 USER MANUAL...
  • Page 2 Document Change History Version Date Description V1.0 2023/07/24 Initial Release. V1.1 2023/10/30 Update DS information AIE-PX13/AIE-PX23 User Manual...
  • Page 3 Aetina be liable to any person for any direct, indirect, special or other consequential damages arising from the use of any information contained herein, even if nvidia is expressly advised of the possibility of such damages.
  • Page 4 Tech_support@aetina.com Product Warranty (2 years) Aetina warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Aetina, or which have been subject to misuse, abuse, accident or improper installation.
  • Page 5 Because of Aetina’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Aetina product is defective, it will be repaired or replaced at no charge during the warranty period. For out of warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
  • Page 6 Exposure to moisture – Device is not working as expected or in a manner as described in this manual – The device is dropped or damaged – vi. Any obvious signs of damage displayed on the device AIE-PX13/AIE-PX23 User Manual...
  • Page 7: Table Of Contents

    5.1 Prepare the Materials ................... 19 5.2 Hardware Connection ................... 19 5.3 Setup Details ......................19 6. EdgeEye ................... 20 6.1 Aetina 360 Edge Administration Platform ............20 6.2 Feature ........................21 6.3 System Requirements ..................21 AIE-PX13/AIE-PX23 User Manual...
  • Page 8: Introduction

    1. Introduction DeviceEdge AGX Orin series – AIE-PX13/AIE-PX23 is a standard system, supporting for NVIDIA Jetson AGX Orin. The system is with smart button for one-key recovery function to address critical system failure and real-time monitoring for status of device through the AIM (Aetina Intelligent Management).
  • Page 9: Specifications

    Idle: Connect with Keyboard, Mouse and HDMI Display Full Loading: Connect with keyboard, mouse, HDMI display and LAN with CPU and GPU 100% loading Dimension (W x D x H) 270 x 195 x 80 mm (10.63 x 7.67 x 3.15 in) AIE-PX13/AIE-PX23 User Manual...
  • Page 10 10 G, IEC 60068-2-27, half sine, 11 ms duration Operating Temperature: -25°C ~ +55°C (-13° F ~ +131° F) with 0.5 m/s air flow Temperature Storage Temperature: -40°C ~ +85°C (-40° F ~ +185° F) Humidity 95% @ 40°C (104°F) (non-condensing) AIE-PX13/AIE-PX23 User Manual...
  • Page 11: Hardware Information

    2. Hardware Information 2.1 I/O Interface Figure 2.1 AIE-PX13/AIE-PX23 I/O Interface 2.2 External Connector Summary Location External Connector Description Front Power Power pushbutton DC IN Power Connector 9V-36V 10G LAN 10 GbE Port 1G LAN 1 GbE Port HDMI HDMI Type-A female connector USB 1 USB3.2 Gen1 Type-A connector...
  • Page 12 ◼ 10G LAN / 1G LAN Item Description Location Front Type RJ-45 Connector ◼ HDMI Item Description Location Front Type HDMI Type-A female connector ◼ Dual USB3.2 Gen1 Type-A connector Item Description Location Front Type Type-A USB connector Refer to USB Standard AIE-PX13/AIE-PX23 User Manual...
  • Page 13 Description Location Rear Type DB15 female connector Pin # Definition Pin # Definition SPI_MOSI SPI_SCK SPI_MISO SPI_CS1 SPI_CS0 I2C_1_CLK I2C_1_DAT I2C_2_CLK I2C_2_DAT 3.3V USB_DM USB_DP ◼ GPIO / UART Item Description Location Rear Type DB15 female connector AIE-PX13/AIE-PX23 User Manual...
  • Page 14 ◼ RS 422 / RS 485 (2-in-1) Item Description Location Rear Type RS-422/RS-485 (2-in-1) Notes Default setting is RS-485 mode (Data-/+) Pin # Definition Pin # Definition TxD+ TxD- RxD-/Data- RxD+/Data+ ◼ RS 232 Item Description Location Rear Type RS-232 AIE-PX13/AIE-PX23 User Manual...
  • Page 15 Definition ◼ CAN1 Item Description Location Rear Type DB9 male connector Pin # Definition Pin # Definition CAL_L CAL_H ◼ CAN2 Item Description Location Rear Type DB9 male connector Pin # Definition Pin # Definition CAL_L CAL_H AIE-PX13/AIE-PX23 User Manual...
  • Page 16 ◼ Reset & Recovery Button Item Description Location Rear Type Pushbutton AIE-PX13/AIE-PX23 User Manual...
  • Page 17: Power Consumption

    USB 3.2 Gen1 Type A (1 port) 4.5 W USB TypeC 4.5 W HDMI 0.25 W M.2 E KEY M.2 M KEY M.2 B KEY CAN Bus SD Card 0.72 W RJ45(PHY) 0.83 W RJ45(10G) 3.43 W AIE-PX13/AIE-PX23 User Manual...
  • Page 18: Mechanical Dimensions

    2.4 Mechanical Dimensions ◼ System & Mounting Dimensions Integration assembly drawing for AIE-PX13/AIE-PX23 system. AIE-PX13/AIE-PX23 User Manual...
  • Page 19: Software Installation

    3. Software Installation Aetina NVIDIA Jetson products have built-in BSP so the users don’t have to install it after getting the products. Since we develop our own BSP, the users may need to follow the BSP installation SOP to re-install/upgrade/downgrade the BSP.
  • Page 20: Initial Setup

    ◼ USB keyboard and mouse ◼ Ethernet cable 5.2 Hardware Connection Here is the AIE-PX13/AIE-PX23 below and for the initial setup, users will need to connect LAN port, keyboard and mouse via USB interface, HDMI interface, and power connector. 5.3 Setup Details...
  • Page 21: Edgeeye

    Introduction To help clients efficiently and systematically manage edge devices deployed in different locations, Aetina offers several cloud management platforms. For example, EdgeEye, an Aetina browser-accessed management platform, allows clients to conveniently manage edge devices via intranet-connected cell phones, tablets, or laptops, no matter where the devices are deployed.
  • Page 22: Feature

    Safari:5.1+ Server Hardware Minimum Requirements: IntelR Core™ i5 2.3 Ghz CPU or above 32 GB RAM 200 GB root partition for the system Operating System: Linux Ubuntu 18.04+ Browser Google Chrome 9.0+ Client Support all Aetina products AIE-PX13/AIE-PX23 User Manual...
  • Page 23 Aetina Corporation | Headquarters 2F-1, No.237, Sec.1, Datong Rd., Xizhi Dist., New Taipei City 221, TAIWAN Phone: +886-2-7709 2568 Fax : +886-2-7746 1102 Mail : sales@Aetina.com www.Aetina.com Copyright © 2022 Aetina Corporation. All rights reserved.
