Configuring your
NetComm NF20 Wi-Fi 6
Note: If you have purchased your NetComm NF20 Wi-Fi 6 from the Tangerine website, it will come
pre-configured and all you'll need to do is follow the set-up process outlined above.
If you have factory-reset your device or purchased from an alternative retailer, please follow these easy
steps to access the configuration page of your NetComm NF20 Wi-Fi 6.
1. Push the power button on the side of the NetComm NF20 Wi-Fi 6 to turn it on. Wait a few minutes for it
to complete start up.
2. Open a web browser and type
3. At the login screen, type in the username and password printed on the label on the bottom of the
NetComm NF20 Wi-Fi 6 and login.
4. Select 'Basic Setup' from the menu on the left-hand side of the screen to begin set up.
If your NBN connection is:
Hybrid Fibre Coaxial (HFC), Fibre to the Premises (FTTP), Fibre to the Curb (FTTC) or Fixed Wireless
1. Select 'Ethernet WAN' as your WAN connection type.
2. Select 'PPPoE' as your WAN mode for your internet connection.
3. Select 'No VLAN Tag' as your VLAN option for your connection.
4. Enter your username and password provided to you in your NBN ordered email.
5. Click the 'Apply/Save' button to complete the setup.
If your NBN connection is:
Fibre to the Node (FTTN), Fibre to the Building (FTTB)
1. Select 'VDSL' as your WAN connection type.
2. Select 'PPPoE' as your WAN mode for your internet connection.
3. If appliable, select 'Custom VLAN Tag' as your VLAN option for your connection and enter 100.
Otherwise select 'No VLAN Tag'.
4. Enter your username and password provided to you in your NBN ordered email.
5. Click the 'Apply/Save' button to complete the setup.
NetComm NF20 Wi-Fi 6 Quick Start Guide
https://192.168.20.1/ into the address bar, then press Enter.
