This user's guide describes the TPS54x80EVM-228 SWIFT regulator
evaluation module (EVM) and contains the EVM schematic, bill of materials,
assembly drawing, and board layouts.
This document contains the following chapters:
-
Chapter 1—Introduction
-
Chapter 2—Test Setup and Results
-
Chapter 3—Board Layout
-
Chapter 4—Schematic and Bill of Materials
-
Appendix A—Out of Phase Synchronization of I/O and Core SWIFT
Famly Regulators
This equipment is intended for use in a laboratory test environment only. It gen-
erates, uses, and can radiate radio frequency energy and has not been tested
for compliance with the limits of computing devices pursuant to subpart J of
part 15 of FCC rules, which are designed to provide reasonable protection
against radio frequency interference. Operation of this equipment in other en-
vironments may cause interference with radio communications, in which case
the user at his own expense will be required to take whatever measures may
be required to correct this interference.
SWIFT and PowerPAD are trademarks of Texas Instruments.
