Enerpac KPR-2 Instruction Sheet

A UNIT OF APPLIED POWER INC.
L- 1446 Rev. A
IMPORTANT RECEIVING INSTRUCTIONS: Visually inspect all components for shipping damage.
If any shipping damage is found, notify carrier at once. Shipping damage is NOT covered by warranty.
The carrier is responsible for all repair or replacement cost resulting from damage in shipment.
Carefully plan your system by selecting components designed to perform the intended operation and
which will adequately perform with existing equipment. Always check the product limitations regarding
pressure ranges, load capacities and set-up requirements. The system operating pressure must not
exceed the pressure rating of the lowest rated component in the system. Read all CAUTIONS,
WARNINGS, and INSTRUCTIONS included with, or attached to, each product. Follow all safety
precautions to avoid personal injury or property damage during the system operation. ENERPAC
CANNOT BE RESPONSIBLE FOR DAMAGE OR INJURY RESULTING FROM UNSAFE USE OF
PRODUCT, LACK OF MAINTENANCE, OR INCORRECT PRODUCT AND SYSTEM APPLICATION.
Contact Enerpac when in doubt as to safety precautions or applications.

DESCRIPTION

Enerpac Pre-Rollers attach to the press bolster to hold and guide the die into and out of the press.
Die stop prevents die from sliding off end of pre-roller. Flip die stop down to remove die.
Be sure die weight does not exceed
rated load capacity of the pre-roller.
Exceeding rating will lead to personal
injury and/or equipment damage.
KPR-3
KPR-2
02/93
SAFETY

WARNING

Instruction Sheet
®
KPR-2, -3, & -5 Pre-Rollers
FIRST
Model
KPR-2
KPR-3
KPR-5
KPR-5

RATED LOAD CAPACITY

Static Load at Tip (Lbs)
1,650 (7,3 kN) max.
1,650 (7,3 kN) max.
3,300 (14,7 kN) max.
