Figure 9: L W Network Bus Topology with T-tap
ON ORKS
To wire a laptop to the L W
ON ORKS
1. Remove the front plate of the EC-Sensor.
2. Connect all three (3) LON cables coming from the previous device, going to the next device and going to the EC-Sensor to the LON1 and LON2 input
terminals on the controller. If inserting multiple wires in the terminals, ensure to properly twist wires together prior to inserting them in the terminal con-
nectors.
3. Connect the LON network cable coming from the controller to the NET+ and NET- terminals on the EC-Sensor.
4. Connect the two (2) wires that terminate with the ⅛" audio cable to the output terminals of the LonTalk
5. Insert the ⅛" audio cable into the communications jack of the EC-Sensor.
Figure 10: Wiring an EC-Sensor to a L
If the distance between the EC-Sensor and the controller (T-tap length) is greater than 10ft (3m), a bus topology must be used. The following figure
shows how the EC-Sensor in bus topology LON network:
Figure 11: L W Network Bus Topology
ON ORKS
6 / 8
22AWG (0.65mm) unshielded
Controller
Sensor
network with T-tap via an EC-Sensor, do the following:
WIRELESS
PORT
W Network Bus Topology with T-tap
ON ORKS
Controller
Sensor
twisted pair network cable
<10ft (3m)
From
Previous
LON2
2
LON1
1
SMRT-
2
SMRT+
1
UI4
5
UI3
4
COM
3
UI2 To
2
UI1
1 Next
UO6
3
COM
2
UO5
1
DO4
6
C3-4
5
DO3
4
DO2
3
C1-2
2
DO1
1
24 VAC
2
24V COM
1
PRESSURE
HIGH LOW
22AWG (0.65mm) unshielded
twisted pair network cable
Bus-topology
network
®
adapter of the laptop.
1/8"
Com.
Jack
Bus-topology
network
