MAINTENANCE
The chain counter does not require any particular maintenance. To assure top performance, check the
cables and electrical connections once a year.
Clean the chain counter with a soft rag dampened in water. Do not use chemicals or harsh products to
clean the chain counter.
TECHNICAL DATA
MODEL
OUTPUT CHARACTERISTICS
UP/DOWN contacts current
External connections
INPUT CHARACTERISTICS
Supply voltage (1)
Current absorbed when idling
Maximum current absorbed
AMBIENT CHARACTERISTICS
Operating temperature
(4)
Degree of protection
(5)
CASE
Dimensions
Weight
GENERAL
Communication interface
Clock battery
EMC class
The chain counter can reset itself if the voltage is less than 9 Vdc.
(1)
Typical value with back-lighting off and windlass not on.
(2)
Typical value with back-lighting on at highest level and windlass on.
(3)
(4) With temperatures below 0°C the crystals in the LCD slow down.
Except for the area where the electric contacts are connected (IP 00).
(5)
QUICK ® RESERVES THE RIGHT TO MODIFY THE TECHNICAL CHARACTERISTICS OF THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT PRIOR NOTICE.
CHC1202M IT GB - REV005B

MAINTENANCE - TECHNICAL DATA

(2)
(3)
CHC 1202 M
4A max
Gold plated male snap-on connector
from 9 to 30 Vdc
35 mA
165 mA + current used by solenoid/reversing solenoid unit
-20 ÷ +70 °C
90 x 94 x 25 [38] mm (94 x 97 x 28 [41] mm with cover)
172 g (204 g with cover)
CAN BUS with differential transceiver
CR2032 (3Vdc)
EN 60945 - FCC Part 15 Rules 47
IP 67
