ironLogic Matrix-IV RF User Manual

Uhf 433.92 mhz reader with connection via ibutton (1-wire) / wiegand-26 / rs-485 protocols
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

MATRIX IV RF
UHF 433.92 MHz reader with connection via
iButton (1-Wire) / Wiegand-26 / RS-485 protocols

1. OVERVIEW.

Matrix-IV RF
RFID reader
433
,92
MHz signals from radio key fobs and then transmit the decoded serial number (code)
acquired from the key fob to the controller via iButton (Dallas Touch Memory) or Wiegand-26
protocols, or to a PC via RS-485 interface.
Reader features.
- Decoding the codes of radio key fobs working by KeeLoq and CAME (TOP432NA,
TOP434NA) protocols.
- Adjustable receiver sensitivity allowing for adjustable radio key fobs reception distance.
- Decodes both fixed and dynamic part of KeeLoq code of IL-100 key fobs. This allows for
blocking clone key fobs at the reader level, when operating in Anti-Clone mode.
(
Note: In Anti-Clone mode, the reader will work only with IL-100 key fobs
- Two output channels to receive key fobs codes, set up separately, allow for flexible ACS
configuration. For example, one reader can be connected to two controllers, and codes from
different radio key fob buttons would be transferred to different channels.
- SMA-F socket to connect an external 433
radio key fobs reception distance by connecting a directional antenna with SMA-M plug.
-
RS-485 interface allows connecting the reader to a PC to acquire radio key fobs codes and to
configure the reader parameters.

2. MOUNTING AND CONNECTION.

The reader should be mounted on a flat surface in a place protected from direct sunlight and
precipitation.
To mount the reader, perform the following steps:
1. Mark and drill the mounting holes of the same size as the holes in the reader casing (see
Figure 1).
2. Connect wires per the layout. Insulate the wire junctions.
3. Power on the reader and check its proper operation by pushing a button on the radio key fob.
4. Mount the reader and fix it in the desired place.
Note:
To ensure operation at a specified distance from controller, you need to use a UTP cable
(e.g. CAT 5e) see Figure 2.
- When connecting via iButton, one wire of the twisted pair is connected to GND, and another to
DATA0.
- When connecting via Wiegand-26, two twisted pairs are needed; the first one is connected
to GND and DATA0 and the second one is connected to GND and DATA1.
-
When connecting via RS-485, one wire of the twisted pair is connected to A, and the other to B
(see Figure 3).
Note:
Reading distance may be reduced significantly when the reader is installed directly onto
a metallic surface, or when there are many metal objects around the installation site.
Matrix IV RF
User Manual
is used in Access Control Systems (ACS) and can receive
,92
MHz antenna allows significantly extending the
www.ironlogic.me
).
page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Matrix-IV RF and is the answer not in the manual?

Questions and answers

Related Manuals for ironLogic Matrix-IV RF

Summary of Contents for ironLogic Matrix-IV RF

  • Page 1 UHF 433.92 MHz reader with connection via iButton (1-Wire) / Wiegand-26 / RS-485 protocols User Manual 1. OVERVIEW. Matrix-IV RF RFID reader is used in Access Control Systems (ACS) and can receive MHz signals from radio key fobs and then transmit the decoded serial number (code) acquired from the key fob to the controller via iButton (Dallas Touch Memory) or Wiegand-26 protocols, or to a PC via RS-485 interface.
  • Page 2 MATRIX IV RF www.ironlogic.me Cable 2. External antenna connection. Cable 1. -Power -Wiegand-26 or iButton output. -RS-485 interface. Fig.1 Table 1.Cable 1 wiring scheme. Wire Colour Wiegand Connection iButton Connection Power +12 24 V Black Common (-) Brown Channel 1...
  • Page 3 When the reader is connected to the PC via RS-485 interface using Z-397 USB 422/485 converter, -- the reader transmits to the PC the following: - Type of key fob: (“IRONLOGIC” (IL-100) / “UNKNOWN” (KeeLoq) / “CAME”) - Key fob code in Wiegand-26 parameter.
  • Page 4 MATRIX IV RF www.ironlogic.me Status indicator Channel 1 indicator Channel 2 indicator Status indicator (see Fig. 4) is used to display the current reader operation mode: - flashing green standard working mode; - flashing red waiting for the new Master key fob to be assigned.
  • Page 5 MATRIX IV RF www.ironlogic.me PACKAGE CONTENTS MATRIX-IV RFRFID reader ....... 1 Type IL-100 radio key fob ........1 Screws 3x30 ............2 Wall plugs ............2 Note: External antenna not included. 7. LIMITED WARRANTY This device is covered by a limited warranty for 24 months from the date of sale.
