ironLogic MATRIX-V Passport And Instruction On Connection And Operation

5. CHARACTERISTICS.

Working frequency: .....................................125 KHz, 433
Type of used identifiers: ...............................EM-Marine, radio charm 433
Range of reading ЕМ-Marine: ........................ till 0.5 (
Range of radio charm reading : ..................... not less 5
Protocols : ...................................................Wiegand 26,
External interface : ........................................Rs485;
Remoteness on iButton : ............................... till 15 ; m
Remoteness on Wiegand : .............................. till 100 ;
Reader remoteness on RS 485: ......................till 1200 (
Indication of operating modes :....................... light and sound
External management of indication :................ available
External management of sound : ................... available
Supply voltage : ...........................................12 V DC
The maximum consumed current : ................500 A; m
Dimensions : ...............................................225х225х36
Material : ..................................................... plastics
Weight : .......................................................1100 . g

6. SERVICE CONDITIONS

Ambient temperature: .................................from - 30C to + 50C.
Relative humidity of air: ................................no more than 90%.
The reader is intended for operation in the conditions of absence:
atmospheric precipitation, direct sunshine and moisture
condensation.

8. GUARANTEE CERTIFICATES

Warranty period of operation of 18 months from the date of sale or 24 months from a date of issue.
Bases for the termination of guarantee certificates:
- violation of the present Instruction;
- existence of mechanical damages;
- existence of traces of influence of aggressive substances;
- existence of traces of unskilled intervention in the scheme.
During a warranty period the Manufacturer free of charge eliminates the malfunctions which have arisen because of the
Manufacturer, or replaces faulty omponents and blocks. c
Repair is made in a workshop of the Manufacturer.
Сертификат ГОСТ Р № РОСС RU.ME83.B00374
Serial number:
Date of issue
Sale date : "_____" _______________________20 ___г.
Seller ___________________________________
www.ironlogic.ru
Mhz ;
s Mhz ;
m with EM-Marine card type-IL-05ELR );
м (with a radio charm type-IL-99);
iButton ;
m
m it is recommended to use the converter USB-485
;
;
;
;
mm ;
;

7. DELIVERY SET

Reader "MATRIX-V" ...........................1 шт.
EM-Marine card type-IL-05ELR
R adio charm 433 MHz type-IL-99 ..........1 шт.
Maintenance instruction ......................1 шт.
Packaging ..........................................1 шт.
_
PASSPORT AND INSTRUCTION ON CONNECTION AND OPERATION
"Z-397" );
.............1 шт.
"MATRIX-V"
Reader ( 125 кГц, 433 МГц)
