ASD -WLP01S-50D50 Manual

LED TRADITIONAL WALLPACK
DESIGN & OPTIONS - LED TRADITIONAL WALLPACK has durable,
▶
commercial-grade die-cast aluminum housing, anti-glare glass shield with high
temperature resistance, maintenance-free LEDs, and anti-leakage silicone gaskets.
This fixture comes with a 120-277V, 0-10V dimmable driver, 3CCT (3,000K, 4,000K or
5,000K with a simple switch) or just 5,000K color temperature and a BRONZE finish.
The field installable optional photocell kit will automatically turn the fixture on/off
depending on the time of day. Built-in EM back-up option provides 90 minutes of
power in case of emergency.
INSTALLATION - The housing features a removable hinge door and
▶
multiple points of entry, making installation quick and easy. The fixture can be
mounted to a junction box or directly to a wall. Refer to installation instructions for
detailed steps.
APPLICATION - These fixtures can operate in temperatures between
▶
-40°+122°F (-40°+50°C), allowing them to be utilized in a wide variety of
applications and climates. This makes them perfect for outdoor security lighting,
wall perimeter lighting, garages, large backyards, commercial loading bays,
warehouses, apartment complexes, hotels, and office/retail complexes.
ENERGY SAVING & EFFICIENCY - This fixture provides a lumen
▶
output equal to MH/HPS and can cut your electric bill by up to 80% instantly. With
a lifespan of 72,000 hours, these fixtures are made to last decades under normal
operation! This fixture will save you a significant amount of money in its lifetime.
CERTIFICATION & WARRANTY - Buy with confidence: ASD provides
▶
a 5-year warranty along with UL and DLC Premium certifications to guarantee top
quality products and safety!
Top US certifications allow participation in rebates; please check the rebate
programs available in your state.
LED TRADITIONAL WALLPACK:
Model Watts
ASD-WLP01S-50D50 50 W
ASD-WLP01-50D50 50 W
ASD-WLP01-80D50 80 W
ASD-WLP01-120D50 120 W
ASD-WLP01S-30DAC 30 W
ASD-WLP01-50DAC 50 W
ASD-WLP01-80DAC 80 W
ASD-WLP01-120DAC 120 W
ASD-WLP01-50DAC-EM 50 W
ASD-WLP01-80DAC-EM 80 W

PRODUCT SPECIFICATIONS:

Construction & Materials
Lens Glass
Housing Die-Cast Aluminum
Finish Bronze
ASD-WLP01S-50D50
ASD-WLP01-50D50
Weight
ASD-WLP01-80D50
ASD-WLP01-120D50
Environmental System
Work Environment Suitable for Wet Locations, IP65
Operating Temperature -40℉ to 122℉ (-40℃ to 50℃)
L-70 Life R > 72,000 hrs; C > 145,000 hrs
ASD LIGHTING CORP
E-mail: orders@asd-lighting.com
Voltage Dimmable Lumens
120-277 V 1-10 V 7,987 lm
120-277 V 0-10 V 7,878 lm
120-277 V 0-10 V 11,874 lm
120-277 V 0-10 V 17,443 lm
120-277 V 1-10 V 4,573/4,890/4,834 lm
120-277 V 1-10 V 7,511/7,719/7,773 lm
120-277 V 1-10 V 11,807/12,174/11,956 lm
120-277 V 1-10 V 16,953/17,703/17,633 lm
120-277 V 1-10 V 7,511/7,719/7,773 lm
120-277 V 1-10 V 11,807/12,174/11,956 lm
5.3 lb (2.4 kg) ASD-WLP01S-30DAC
7.9 lb (3.6 kg) ASD-WLP01-50DAC
8.2 lb (3.7 kg) ASD-WLP01-80DAC
9.3 lb (4.2 kg) ASD-WLP01-120DAC
Web site: www.asd-lighting.com
Catalog number
Notes
Type
CCT Option
5,000 K
5,000 K
5,000 K
5,000 K
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K) Battery back-up
3CCT (3,000/4,000/5,000 K) Battery back-up
5.3 lb (2.4 kg) ASD-WLP01-50DAC-EM
8 lb (3.7 kg) ASD-WLP01-80DAC-EM
8.3 lb (3.8 kg)
9.4 lb (4.3 kg)
For most up-to-date spec sheets please refer to asd-lighting.com
English
Dimensions (LxWxH)
- 10 1/4" x 9 1/2"x 7 1/2"
- 14 1/4" x 9 5/16"x 7 9/16"
- 14 1/4" x 9 5/16"x 7 9/16"
- 14 1/4" x 9 5/16"x 7 9/16"
- 10 1/4" x 9 1/2"x 7 1/2"
- 14 1/4" x 9 5/16"x 7 9/16"
- 14 1/4" x 9 5/16"x 7 9/16"
- 14 1/4" x 9 5/16"x 7 9/16"
14 1/4" x 9 5/16"x 7 9/16"
14 1/4" x 9 5/16"x 7 9/16"
9.1 lb (4.2 kg)
9.4 lb (4.3 kg)
