LED Full Cutoff Wallpack
Standard Series
ASD Full-cutoff wallpacks offer controlled light output for general-purpose area and security lighting. Dark-sky compliant.
Ideal replacement for up to 250-watt HID fixtures.
Die-cast aluminum housing with dark bronze finish. Mounts to junction box or directly to wall. Full-cutoff LED wall pack is a
perfect replacement for traditional outdoor wall packs.
FEATURES AND BENEFITS:
▶
Replaces up to 250 Watt Metal Halide
▶
Fixture is full cutoff version (no uplight)
▶
Impact-resistant polycarbonate optical lens
▶
No maintenance
▶
Operating temperature of -40℉ to 104℉
▶
Wet location IP65
▶
L-70 Life > 75,000 hrs
▶
cULus certified
▶
DesignLights Consortium (DLC) listed
(Classification: Standard)
▶
5 Year warranty
ORDERING MATRIX:
Family
ASD-WLP
LED Full Cutоff Wallpack
LED FULL CUTOFF WALLPACK:
Model
ASD-WLP03-50N50
ASD-WLP03-80D50
E-mail:
orders@asd-lighting.com
WebSite:
www.asd-lighting.com
Modification
03
Watts
Dimming Compatible
50
No
80
Yes
Phone:
781-739-3977
Fax:
339-502-8970
110
lm
w
HIGH LUMINOUS
EFFICIENCY
Watts
Dimmable 0~10 V / N
XX
X
50
= 50 W
N
= Non-dimmable
80
= 80 W
D
= Dimmable
CCT
Lumens
5,000 K
5,798 lm
5,000 K
9,128 lm
CCT
50
5,000 K
Dimensions (LxWxH)
14"x 9 1/4"x 8 1/4"
14"x 9 1/4"x 8 1/4"
Advertisement
Related Manuals for ASD Standard Series
Summary of Contents for ASD Standard Series
- Page 1 LED Full Cutoff Wallpack Standard Series ASD Full-cutoff wallpacks offer controlled light output for general-purpose area and security lighting. Dark-sky compliant. Ideal replacement for up to 250-watt HID fixtures. Die-cast aluminum housing with dark bronze finish. Mounts to junction box or directly to wall. Full-cutoff LED wall pack is a perfect replacement for traditional outdoor wall packs.
-
Page 2: Product Specifications
LED Full Cutoff Wallpack Standard Series PRODUCT SPECIFICATIONS: Construction & Materials Lens Reflector Aluminum Housing Aluminum Finish Bronze Weight ASD-WLP03-50N50 5.46 lb (2.48 kg) ASD-WLP03-80D50 6.16 lb (2.8 kg) Environmental System Work Environment Suitable for Wet Locations, IP65 Operating Temperature -40℉... - Page 3 LED Full Cutoff Wallpack Standard Series FULL CUTOFF WALLPACK ORDERING INFORMATION: Model Watts Product Pcs in one Carton Size Carton Weight Code Carton ASD-WLP03-50N50 5,000 K 857622006831 026.0118 15.55"x8.66"x9.64" 6.16 lbs ASD-WLP03-80D50 5,000 K 857622006848 026.0119 15.55"x8.66"x9.64" 6.82 lbs 50 W, 80 W 14.3”...
- Page 4 Risk of Fire: Minimum 90°С supply conductors. Consult a qualified electrician to ensure correct branch circuit conductor. ASD® assumes no responsibility for claims arising out of improper or careless Installation or handling of this product. AVERTISSEMENT RISQUE DE BLESSURES - Lisez et suivez toutes les MISES EN GARDE et les instructions d’installation.
-
Page 5: Important Safety Information
LED Full Cutoff Wallpack Standard Series INSTALLATION GUIDE IMPORTANT SAFETY INFORMATION: Please read all the instructions below before installation. ▶ Make sure that the supply voltage corresponds to the rated product voltage. ▶ The product must be installed by a qualified electrician in accordance with the National Electrical Code and corresponding local codes.
