LED COB Cut-Off Wallpack
Standard Series
Our slim LED wallpacks are designed to replace up to a 460w metal halide
producing an abundance of light with a fraction of the power. These low profile
durable fixtures are great for a downlight or uplight and are easily installed.
We offer a 5 year warranty with 36,000 hour L70 lifespan. This is an ideal
commercial outdoor fixture for buildings, parking garages, schools, and ware-
houses, is suitable for wet locations and harsh environments.
FEATURES AND BENEFITS:
▶
5 Year warranty
▶
LED lifetime (L70) > 36,000 hrs
▶
No maintenance
▶
Economical replacement
for an old outdated metal halide wallpack
▶
Low profile design
▶
Wet location IP65
▶
Operating temperature of -40-104℉
▶
cULus certified
▶
DesignLightsTM Consortium (DLC)
listed (4.0 standard)
ORDERING MATRIX:
Family
ASD-WLP
LED COB Cut-Off Wallpack
LED COB CUT-OFF WALLPACK:
Model
ASD-WLP02-30N50
ASD-WLP02-50N50
ASD-WLP02-75N50
ASD-WLP02-100N50
E-mail:
info@asd-lighting.com
WebSite:
www.asd-lighting.com
Modification
02
100
Watts
Dimming Compatible
30 W
NO
50 W
NO
75 W
NO
100 W
NO
Phone:
781-739-3977
Fax:
339-502-8970
HIGH LUMINOUS
Watts
Dimmable
XX
N
30
= 30 W
Non-dimmable
50
= 50 W
75
= 75 W
= 100 W
CCT
Lumens
5000 K
2,850 lm
5000 K
4,750 lm
5000 K
7,125 lm
5000 K
10,000 lm
100
lm
IP65
w
rated
EFFICIENCY
CCT
50
5000 K
Dimensions (L x W x H)
7.9" x 6.6" x 4.25"
7.9" x 6.6" x 4.25"
11.6" x 9.5" x 5.9"
11.6" x 9.5" x 5.9"
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ASD Standard Series
Summary of Contents for ASD Standard Series
- Page 1 LED COB Cut-Off Wallpack Standard Series Our slim LED wallpacks are designed to replace up to a 460w metal halide producing an abundance of light with a fraction of the power. These low profile IP65 durable fixtures are great for a downlight or uplight and are easily installed.
-
Page 2: Product Specifications
LED COB Cut-Off Wallpack Standard Series PRODUCT SPECIFICATIONS: Construction & Materials Lens Glass Reflector Aluminum Housing Aluminum Finish Color Black ASD-WLP02-30N50 3.6 lb (1.65 kg) ASD-WLP02-75N50 9 lb (4.1 kg) Weight ASD-WLP02-50N50 3.9 lb (1.8 kg) ASD-WLP02-100N50 9.4 lb (4.2 kg) - Page 3 LED COB Cut-Off Wallpack Standard Series LED COB CUT-OFF WALLPACK ORDERING INFORMATION: Product Pcs in one Carton Model Watts GTIN 12 GTIN 14 Carton Size Code Carton Weight ASD-WLP02-30N50 30 W 5000 K 857622006428 10857622006425 026.0101 16.9"x9.1"x14.4" 34.3 lbs ASD-WLP02-50N50...
- Page 4 Risk of Fire: Minimum 90°С supply conductors. Consult a qualified electrician to ensure correct branch circuit conductor. ASD® assumes no responsibility for claims arising out of improper or careless Installation or handling of this product. AVERTISSEMENT RISQUE DE BLESSURES - Lisez et suivez toutes les MISES EN GARDE et les instructions d'installation.
-
Page 5: Important Safety Information
LED COB Cut-Off Wallpack Standard Series INSTALLATION GUIDE IMPORTANT SAFETY INFORMATION: Please read all the instructions below before installation. ▶ Make sure that the supply voltage corresponds to the rated product voltage. ▶ The product must be installed by a qualified electrician in accordance with the National Electrical Code and corresponding local codes. -
Page 6: Wall Mount
LED COB Cut-Off Wallpack Standard Series CONNECTING MULTIPLE FIXTURES TO ONE SWITCH Remove screw and open the cover. Affix gaskets ¾ (gaskets are not included and should be purchased separately). gasket Insert power cord and cord going to the next linking fixture.
