LED Area and Roadway light
Standard Series
ASD Area and Roadway lighting with dusk-to-dawn photocell provides optimal illumination for side doors, backdoors,
garages, sheds etc.
Keep your property secure with these ultra-bright security lights, designed to save on electricity bills while
providing exceptional surface coverage. The 50W LED barn light is the perfect replacement for the 100W MH
traditional lighting fixture.
Our new LED Area and Roadway light will turn on automatically when the environment gets dark
without the user having to flipping the switch.
FEATURES AND BENEFITS:
▶
Twist-lock photocell included
▶
Mounts directly or with mounting arm (included)
▶
Durable Die-Cast Aluminum Housing
▶
No maintenance
▶
Operating temperature of -40℉ to 104℉
▶
Wet location IP65
▶
L-70 Life > 54,000 hrs
▶
cULus certified
▶
DesignLights Consortium (DLC) listed
(Classification: Standard)
▶
5 Year warranty
ORDERING MATRIX:
Family
ASD-ARL
LED Area and Roadway light
LED AREA AND ROADWAY LIGHT:
Model
ASD-ARL-50N30-PC
ASD-ARL-50N40-PC
ASD-ARL-50N50-PC
ASD-ARL-50N60-PC
E-mail:
info@asd-lighting.com
WebSite:
www.asd-lighting.com
Watts
XX
50
= 50 W
Watts
Dimming Compatible
50
No
50
No
50
No
50
No
Phone:
781-739-3977
Fax:
339-502-8970
Dimmable
N
N
= Non-dimmable
CCT
Lumens
3,000 K
5,326 lm
4,000 K
5,326 lm
5,000 K
5,326 lm
6,000 K
5,326 lm
110
lm
w
HIGH LUMINOUS
EFFICIENCY
CCT
Photocell
XX
PC
3,000 K
4,000 K
5,000 K
6,000 K
Dimensions (LxWxH)
24"x 9 1/2"x 21 1/4"
24"x 9 1/2"x 21 1/4"
24"x 9 1/2"x 21 1/4"
24"x 9 1/2"x 21 1/4"
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ASD Standard Series
Summary of Contents for ASD Standard Series
- Page 1 LED Area and Roadway light Standard Series ASD Area and Roadway lighting with dusk-to-dawn photocell provides optimal illumination for side doors, backdoors, garages, sheds etc. Keep your property secure with these ultra-bright security lights, designed to save on electricity bills while providing exceptional surface coverage.
- Page 2 LED Area and Roadway light Standard Series PRODUCT SPECIFICATIONS: Construction & Materials Lens Reflector Aluminum Housing Aluminum Finish Bronze Weight 5.94 lbs (2.7 kg) Environmental System Work Environment Suitable for Wet Locations, IP65 Operating Temperature -40℉ to 104℉ (-40℃ to 40℃) L-70 Life >...
- Page 3 LED Area and Roadway light Standard Series 50 W 7” (177.8 mm) 9.5” (240 mm) 21.25” (540 mm) E-mail: info@asd-lighting.com Phone: 781-739-3977 WebSite: Fax: www.asd-lighting.com 339-502-8970...
- Page 4 Risk of Fire: Minimum 90°С supply conductors. Consult a qualified electrician to ensure correct branch circuit conductor. ASD® assumes no responsibility for claims arising out of improper or careless Installation or handling of this product. AVERTISSEMENT RISQUE DE BLESSURES - Lisez et suivez toutes les MISES EN GARDE et les instructions d’installation.
- Page 5 LED Area and Roadway light Standard Series INSTALLATION GUIDE IMPORTANT SAFETY INFORMATION: Please read all the instructions below before installation. ▶ Make sure that the supply voltage corresponds to the rated product voltage. ▶ The product must be installed by a qualified electrician in accordance with the National Electrical Code and corresponding local codes.
- Page 6 LED Area and Roadway light Standard Series INSTALLATION STEPS DIRECTLY FIX TO MOUNTING SURFACE: 1. Fix cord protection bracket by two hex socket screws. 2. Use expansion bolts to secure the fixture on mounting surface. 3. Keep enough length wires to ensure adjusting angle 3.34”...
