SPEEDLINK SL-890009-BK - Stereo Speaker Manual

How to use

1. Charge the speaker by connecting it to a USB power source (min. 500mA) using the micro- USB charging cable. During charging (approx. 2.5 hours), the LED will glow red. Be aware that the initial charge may take a little longer. As soon as the LED goes out, the charging process is complete and you can disconnect the cable.


2. Switch the speaker on ('ON') – the front LED will flash blue quickly to indicate the connection readiness.


3. Pair your smartphone or tablet to the speaker ('SPEEDLINK JUKX) via BLUETOOTH process differs depending on the device. If requested, enter the code 0000. The LED behind the grill will now slowly flash blue. The connection will be re-established automatically after switching the devices off and back on again (be aware that this process can take approx. 20 seconds).


4. Alternatively, connect the speaker to an audio source using the audio cable (3.5mm).


5. The speaker buttons control playback and telephone functions. Refer to the table for additional button functions. Be aware that some of these functions are only available when connected via BLUETOOTH ®.

   Function*	Button operation
   Increase volume	Press repeatedly
   Decrease volume	Press repeatedly
   Play/pause	Press (music playback)
   Next track	Press (music playback)
   Previous track	Press (music playback)
   Answer call	Press (incoming call)
   Decline call	Press and hold for 3s (incoming call)
   End call	Press (in a call)
   Redial	Press and hold for 3s

   * Device dependent; some functions only available in Bluetooth

6. To switch to memory card mode, insert a micro- SD memory card into the memory card slot as shown. The speaker will switch automatically to memory card mode and play back the audio files on the micro-SD card. The micro-SD card must be formatted as FAT/FAT32 and contain MP3, WMA or WAV files.


7. As soon as you hear a warning sound, you notice a drop in performance or the device switches itself off automatically, recharge the speaker. If you do not intend to use the speaker, simply switch it off ('OFF') to save power.


© 2015 Jöllenbeck GmbH. All rights reserved. SPEEDLINK, the SPEEDLINK word mark and the SPEEDLINK swoosh are registered trademarks of Jöllenbeck GmbH. The BLUETOOTH^® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Jöllenbeck GmbH is under license.
All trademarks are the property of their respective owner. Jöllenbeck GmbH shall not be made liable for any errors that may appear in this manual. Information contained herein is subject to change without prior notice. Please keep this information for later reference.
JÖLLENBECK GmbH, Kreuzberg 2, 27404 Weertzen, GERMANY
