ENSIM SENSORS ELC 21d Operating Manual page 3

Technical Specifications:
Electrode Material
Isolation of Electrode
Connection Material
Case
Max. Working Temp.
Max. Working Pressure
Number of Electrode
Voltage Probe
Mechanical Connection (R)
Electrical Connection
Technical Specifications:
Electrode Material
Isolation of Electrode
Connection Material
Case
Max. Working Temp.
Max. Working Pressure
Number of Electrode
Voltage Probe
Mechanical Connection (R)
Electrical Connection
LEVEL CONTROL RELAY
SK-P3
4 pcs. 5 A 1 pc. 5 A Start - Stop Relay
Independent Relay 2 pcs. 5 A Min. - Max. Relay
304 Stainless Steel
Opt. 316 Stainless Steel
PTFE
304 Stainless Steel
Opt. 316 Stainless Steel
304 Stainless Steel
Opt. 316 Stainless Steel
Max. 200 °C
25 Bar
Max. 4
Max.6 VAC
1" BSP (Std)
DIN 43650A (ISO4400)
304 Stainless Steel
Opt. 316 Stainless Steel
Delrin Opt. PTFE
Delrin Opt. PTFE
PBT
80 °C Opt.120 °C
25 bar
Max.5
Max. 6 VAC
2" BSP (Std)
PG 13,5
SK-P4
+
All dimensions are given in mm.
Plastic
Delrin
R
Ø8
L5
L1 L2 L3 L4 L5
3
ELC 21 , ELC 31 , ELC 41
Ø38
41 HEX
R
L4 L1
L2 L1
ELC 21p , ELC 31p
ELC 41p , ELC 51p
74 HEX
L1
L2
L3
L4
L3 L2
