Table 4. Unit dimensions (in.)—TWO-PIECE unit —WITHOUT energy recovery wheel (continued)
Unit Width
Blank
Tons
Section
M
None 139 13/16
90 4 ft 139 13/16
8 ft 139 13/16
None 139 13/16
105 4 ft 139 13/16
8 ft 139 13/16
120-150
None 139 13/16
(a)
120-150
4 ft 139 13/16
(a)
120-150
8 ft 139 13/16
(a)
120-150
None 139 13/16
(b)
(a) High Heat Gas Models Only
(b) High Heat Gas Models Only
Table 5. Unit dimensions (in.)—TWO-PIECE unit —WITH energy recovery wheel
Blank
Tons
Section
A
None 550 11/16
90 4 ft 598 14/16
8 ft 647 2/16
None 568 11/16
105 4 ft 616 14/16
8 ft 665 2/16
120-
None 642 7/16
(a)
150
120-
4 ft 690 10/16
(a)
150
120-
8 ft 738 14/16
(a)
150
120-
None 654 7/16
(a)
150
Unit Width
Blank
Tons
Section
M
None 139 13/16
90 4 ft 139 13/16
8 ft 139 13/16
None 139 13/16
105 4 ft 139 13/16
8 ft 139 13/16
120-
None 139 13/16
(a)
150
120-
4 ft 139 13/16
(a)
150
120-
8 ft 139 13/16
(a)
150
120-
None 139 13/16
150 (b)
(a) High Heat Gas Models Only
(b) High Heat Gas Models Only
RT-SVX073A-EN
Unit Height
N O P
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
Unit Dimensions
B E F
256 5/16 427 5/16 121 6/16
256 5/16 475 8/16 121 6/16
256 5/16 523 12/16 121 6/16
256 5/16 427 5/16 139 6/16
256 5/16 475 8/16 139 6/16
256 5/16 523 12/16 139 6/16
293 8/16 492 1/16 148 6/16
293 8/16 540 4/16 148 6/16
293 8/16 588 8/16 148 6/16
293 8/16 504 1/16 148 6/16
Unit Height
N O P
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
143 8/16 103 12/16 97 9/16
Return Exhaust
Fan Fan
R J K
103 7/16 29 3/16 17
103 7/16 29 3/16 17
103 7/16 29 3/16 17
103 7/16 29 3/16 17
103 7/16 29 3/16 17
103 7/16 29 3/16 17
103 7/16 29 3/16 17
103 7/16 29 3/16 17
103 7/16 29 3/16 17
103 7/16 29 3/16 17
Lifting Lug Locations
Air Handler Side
C1 C2 C3
66 201 1/16 349 4/16
66 201 1/16 349 4/16 464 13/16
66 201 1/16 349 4/16
66 201 1/16 349 4/16
66 201 1/16 349 4/16 464 13/16
66 201 1/16 349 4/16
66 238 5/16 365 5/16 480 14/16
66 238 5/16 365 5/16
66 238 5/16 365 5/16
66 238 5/16 365 5/16 492 14/16
Return Exhaust
Fan Fan
R J K
103 7/16 N/A 17
103 7/16 N/A 17
103 7/16 N/A 17
103 7/16 N/A 17
103 7/16 N/A 17
103 7/16 N/A 17
103 7/16 N/A 17
103 7/16 N/A 17
103 7/16 N/A 17
103 7/16 N/A 17
Dimensional Data
Lug Locations
Condenser Side
C4 D1 D2
N/A 16 112 7/16
16 112 7/16
513 16 112 7/16
N/A 16 130 7/16
16 130 7/16
513 16 130 7/16
16 139 7/16
529 2/16 16 139 7/16
577 5/16 16 139 7/16
16 139 7/16
