Ruckus Wireless ZF7731 Quick Setup Manual

Fiber Node
Mounting Bracket Kit
Quick Setup Guide
This Quick Setup Guide provides step-by-step
instructions on how to mount two Ruckus Wireless
devices back-to-back on a pole using the fiber node
mounting bracket kit (part number 902-0109-0000).
S D
UPPORTED EVICES
The devices can be Ruckus Wireless Fiber Nodes and/or
TM
ZoneFlex Access Points, including the following:
• Ruckus Wireless Fiber Node (FN)
• ZoneFlex (ZF) 7731 Point to Point Wireless Bridge
(Note 1)
• ZF7761-CM Outdoor Access Point (AP) with
Integrated Cable Modem (Note 1)
• ZF7762 Outdoor AP with internal omni antennas
• ZF7762-AC Outdoor AP with internal omni antennas
• ZF7762-S Outdoor AP with internal 2.4GHz sector
antenna (Note 1)
• ZF7762-S-AC Outdoor AP with internal 2.4GHz sector
antenna (Note 1)
• ZF7762-T Outdoor AP with internal 2.4GHz omni
antenna (Note 1)
Copyright © 2012 Ruckus Wireless, Inc.
Published December 2012, Part Number 800-70417-001 Rev A
NOTE 1:
ZF7731, ZF7761-CM, ZF7762-S, ZF7762-S-AC and ZF7762-T
APs require customer-supplied 5GHz external antennas to
support Smart Mesh communications.
NOTE 2:
Ruckus Wireless products must be installed by a
professional installer.
WARNING!
Mounted equipment must be grounded. If the fiber node
TM
mounting bracket is not grounded, then you must ground
the mounted equipment by connecting a customer-
supplied ground wire to the grounding lug on one
mounted device, and then connecting the other end to a
reliable earth ground. If you are uncertain if suitable
grounding is available, then contact the appropriate
electrical inspection authority or an electrician.
WARNING!
A short-circuit backup protection device must be
connected to AC-powered equipment according to local
or national electrical codes.
P C
ACKAGE ONTENTS
• One set:
- pole mounting base
- extension arm
- dual-slide adapter bracket
- two sets stainless steel 40mm M8 x 1.25 bolts, each
with lock and flat washers
• Four stainless steel clamps 12.7mm (0.5") wide x
63.5mm (2.5") diameter
• Two sets: device mounting bracket, each with two
23mm M6 x 1 stainless steel captive socket cap screws
and captive springs
• 8 sets: 0.5" 0.250-28 stainless steel flat head phillips
screws
• 8 sets: 12mm M4 stainless steel oversized flat head
phillips screws
• This Quick Setup Guide
B Y B
EFORE OU EGIN
Before deploying your Ruckus Wireless device, please
check the Ruckus Wireless Web site for the latest
software and release documentation.
• Release Notes and User Guides are available at
http://support.ruckuswireless.com/documents.
• Software Upgrades are available at
http://support.ruckuswireless.com/software.
• Open Source information is available at
http://support.ruckuswireless.com/open_source.
R T S
EQUIRED OOLS AND UPPLIES
• Phillips screwdriver
• 5mm (3/16") long arm hex ball driver
• 13mm (0.5") hex socket
• Ratchet wrench
• Torque wrench
• Torque screwdriver
• Purple Loctite or equivalent thread locker formulated
for normal small-fastener disassembly with standard
hand tools
Page 1 of 2
