Ruckus Wireless Fiber Node Quick Setup Manual

Fiber Node
Quick Setup Guide
This Quick Setup Guide provides step-by-step
instructions for setting up your Ruckus Wireless
Node (FN).
WARNINGS!
This is a Class 1 laser product.
The laser radiates when the system is open and the
interlocks are bypassed.
Ruckus Wireless products must be installed, serviced and
replaced by a professional installer.
WARNING!
Mounted equipment must be grounded. If the fiber node
mounting bracket is not grounded, then you must ground
the mounted equipment by connecting a customer-
supplied ground wire to the grounding lug on one
mounted device, and then connecting the other end to a
reliable earth ground. If you are uncertain if suitable
grounding is available, then contact the appropriate
electrical inspection authority or an electrician.
WARNING!
A short-circuit backup protection device must be
connected to AC-powered equipment according to local
or national electrical codes.
Copyright © 2013 Ruckus Wireless, Inc.
Published November 2013, Part Number 800-70378-001 Rev C
B Y B
EFORE OU EGIN
Before deploying your Ruckus Wireless device, please
check the Ruckus Wireless Web site for the latest
software and release documentation.
• Release Notes and User Guides are available at
http://support.ruckuswireless.com/documents
• Software Upgrades are available at
http://support.ruckuswireless.com/software
• Open Source information is available at
http://support.ruckuswireless.com/open_source
TM Fiber
P C
ACKAGE ONTENTS
• Fiber Node enclosure
• One set:
- pole/wall mounting base
- extension arm
- dual-slide adapter plate
- two sets stainless steel 40mm M8 x 1.25 bolts, each
with lock and flat washers
• Four stainless steel clamps 12.7mm (0.5") wide x
63.5mm (2.5") diameter
• Two sets: device mounting bracket, each with two
23mm M6 x 1 stainless steel captive socket cap screws
and captive springs
• 4 sets: 0.5" 0.250-28 stainless steel flat head Phillips
screws
• M25-to-5/8" thread adapter and O-ring (for use with
optional customer-supplied FOTC (fiber optic trunk
cable)
• This Quick Setup Guide
R T S
EQUIRED OOLS AND UPPLIES
• Phillips screwdriver
• 5mm (3/16") long arm hex ball driver
• 13mm (0.5") hex socket
• Ratchet wrench
• Torque wrench
• Torque screwdriver
• Purple Loctite or equivalent thread locker formulated
for normal small-fastener disassembly with standard
hand tools
O S
PTIONAL UPPLIES
• Customer-supplied FOTC (fiber optic trunk cable),
including strain relief connector and fitting nut
• Customer-supplied FOTC heat-shrink tubing
• If required for attaching a safety cable to the Fiber
Node enclosure, one customer-supplied set of
stainless steel 12mm M6x1 panhead Phillips screws
with split lock and flat washers
Page 1 of 4
