Ruckus Wireless ZoneFlex P300 Quick Setup Manual

START HERE
ZoneFlex P300 Wireless Bridge
TM

Quick Setup Guide

Note: This Quick Setup Guide is designed to work with the ZoneFlex
P300 Wireless Bridge Mounting Guide. Complete the procedures in
this document before continuing with the Mounting Guide.
Note: The minimum software revision for the ZoneFlex P300 is base
image 100.1.0.9 or later. FlexMaster requires firmware 9.12 and later
to manage the ZoneFlex P300.
This Quick Setup Guide provides information on how to configure the
Ruckus Wireless ZoneFlex P300 802.11ac point-to-point and point-to-
multipoint outdoor wireless bridge on the network. The ZoneFlex P300 can
use its internal 5GHz antennas, or can optionally use a two-port customer-
ordered external 5GHz antenna. After completing the steps described in
this Guide, you will be able to place the ZoneFlex P300 at your site. The
rest of this guide refers to the ZoneFlex P300 wireless bridge as the
ZoneFlex P300, root bridge, or non-root bridge.
The ZoneFlex P300 can be ordered either as an unconfigured single
ZoneFlex P300, or as a pre-configured matched pair of ZoneFlex P300s.
These ZoneFlex P300s are almost always installed in pairs, where one is
configured as a root bridge and the other as a non-root bridge.
The ZoneFlex P300 can be deployed as a root bridge connected to the
Ethernet backhaul, or can be deployed as a non-root bridge connected to
the root bridge via the wireless link. The ZoneFlex P300 can be equipped
with customer-purchased external 5GHz antennas to increase the root
bridge-to-non-root bridge connectivity range, or to increase the number of
non-root bridges that a root bridge can communicate with.
Figure 1. ZoneFlex P300s deployed as root bridge and non-root bridge
root bridge
non-root bridge root bridge
Note: When deployed in the root bridge--non-root bridge -to- root bridge--
non-root bridge configuration, the two wireless links must use different
SSIDs.
Copyright © 2015 Ruckus Wireless, Inc.
Published 7 July 2015, Part Number 800-70607-001 Rev B
This Guide in Other Languages
请从以下网站获得该指南的简体中文版
https://support.ruckuswireless.com
Vous trouverez la version française de ce guide à l'adresse suivante
https://support.ruckuswireless.com
こ の ガ イ ド の日本語版は
で ご 覧 く だ さ い
이 가이드의 한국어 버전은 웹 사이트
(https://support.ruckuswireless.com) 에서 확인하시기 바랍니다
Veja a versão em português (Brasil) deste guia em
https://support.ruckuswireless.com
Puede ver la versión en español (América Latina) de esta guía en
https://support.ruckuswireless.com
Before You Begin
Before deploying Ruckus Wireless products, please check for the latest
software and the release documentation.
• User Guides and Release Notes are available at
http://support.ruckuswireless.com/documents
• Software Upgrades are available at
http://support.ruckuswireless.com/software
• Open Source information is available at
http://opensource.ruckuswireless.com
• Software License and Limited Warranty are available at
http://support.ruckuswireless.com/warranty
Safety Warnings
• WARNING! Only trained and qualified personnel should be allowed to
install, replace, or service this equipment. The professional installer is
responsible for the proper installation and configuration of this
ZoneFlex P300. The ZoneFlex P300 installation must comply with local
regulatory requirements, especially with those regulating operation
near military and/or weather radar systems.
• WARNING! Installation of this equipment must comply with local and
national electrical codes.
• WARNING! Ruckus Wireless strongly recommends that you wear eye
protection before mounting the ZoneFlex P300.
• WARNING! The Ruckus Wireless PoE injector (ordered separately) is
for indoor use only. Never mount the PoE injector outdoors with the
ZoneFlex P300.
• CAUTION: Make sure that you form a 80mm - 130mm (3"-5") drip
loop in any cable that is attached to the ZoneFlex P300 or the building.
This will prevent water from running along the cable and entering the
ZoneFlex P300 or the building where the cable terminates.
• CAUTION: Be sure that grounding is available and that it meets local
and national electrical codes. For additional lightning protection, use
non-root bridge
lightning rods and lightning arrestors.
• NOTE: Allowable external antenna types and antenna gains may be
limited by local regulatory requirements.
non-root bridge
https://support.ruckuswireless.com
Package Contents
Before configuring or deploying your ZoneFlex P300, verify that all items
listed below are included in the package. If any item is damaged or
missing, notify your authorized Ruckus Wireless sales representative.
One or two ZoneFlex P300 kits, depending on ordered part:
• 901-P300-xx01, ZoneFlex P300, 802.11ac 5GHz point-to-point
wireless bridge, includes one ZoneFlex P300 kit
• 901-P300-xx02, ZoneFlex P300, 802.11ac 5GHz point-to-point
wireless bridge, pre-provisioned pair, includes two ZoneFlex P300 kits
where 'xx' is a country-specific code.
Each ZoneFlex P300 kit contains:
• One ZoneFlex P300, which includes a 12mm stainless steel M6x1
Phillips earth ground screw with split lock and flat washers (A in
2)
• One M25 data cable gland (B in Figure 2)
• One green/yellow earth ground wire with ring terminal (C in
• One wall- or pole-mounting bracket (D in
• One U-joint bracket (E in Figure 2)
• One linkage bracket with two serrated external-tooth lock washers (F
in Figure 2)
• One ZoneFlex P300 bracket (G in Figure 2)
• Two sets 50mm stainless steel M8x1.25 hex bolt with split lock and
flat washers (H in Figure 2)
• Four SAE32-sized stainless steel clamps, 38.1mm to 63.5mm (1.5" to
2.5") inner diameter (I in Figure 2)
• Four sets stainless steel 8mm M4x0.7 pan head Phillips screws with
split lock and flat washers (J in Figure 2)
• Eight sets stainless steel 0.5-inch x 0.250-28 hex bolt with split lock
and flat washers (K in Figure 2)
• Service Level Agreement/Limited Warranty Statement
• Regulatory Statement
• Declaration of Conformity, if required
• This Quick Setup Guide
• ZoneFlex P300 Wireless Bridge Mounting Guide
• N-Type Connector Sealing Instructions
NOTE: This kit includes extra bolts, nuts and washers. You may use the
extras wherever required.
Figure 2. ZoneFlex P300 field-installation kit contents
A B C D E
H I J
Figure
Figure 2)
Figure 2)
F G
K
Page 1 of 4
