Wir Wireless Optical Dissolv eless Optical Dissolved Oxy
PS-3224
This device measures the concentration and saturation percentage of
dissolved oxygen molecules in aqueous solutions. It also
simultaneously measures temperature and oxygen gas concentration.
When the protective cover is installed, the device is waterproof to a
depth of 10 meters.
Items list Items list
What's Included What' s Included
• Wireless Optical Dissolved Oxygen Sensor
• Protective Cover
• USB Cable
Requir Required Items ed Items
• Data Collection Software Data Collection Software
This product requires PASCO software for data collection and
analysis. Either SPARKvue or PASCO Capstone can be used.
Recommended Items Recommended Items
• Metal Guard (PS-3604) Metal Guard (PS-3604)
Protects the sensing element of the Wireless Dissolved Oxygen
Sensor when using the sensor in the field. The guard also helps
weigh the sensor down when submerged.
ed Oxygen Sensor gen Sensor
P P ar art descriptions t descriptions
T T op View op View
1
2
Battery Status Light Battery Status Light
1
Indicates the battery level and charging status.
L L
IGHT
Red (blink)
Green (solid)
Yellow (solid)
Bluetooth Status Light Bluetooth Status Light
2
Indicates the status of the Bluetooth connection.
L L
IGHT
Red (blink)
Green (blink)
Yellow (blink)
Device ID Device ID
3
Use to identify the sensor when connecting using Bluetooth.
USB Port USB Port
4
Use with the USB cable to connect to a USB wall charger to
charge the battery. Can also be used to send measurement data
to software when connected to a USB port of a computer or
mobile device (iOS devices not supported).
Power Button Power Button
5
Press and hold for one second to turn the sensor on or off.
wireless Optical
Dissolved Oxygen
XXX XXX
3
4
S S
TATUS
Low battery level
Fully charged
Charging
S S
TATUS
Ready to pair
Paired
Remotely logging data
Wireless Optical Dissolved Oxygen Sensor | 1
Product Guide
012-16057B
5
